![TEL 5-2423 TEL 5-2423](https://ce8dc832c.cloudimg.io/v7/_cdn_/97/A2/D0/00/0/862841_1.jpg?width=640&height=480&wat=1&wat_url=_tme-wrk_%2Ftme_new.png&wat_scale=100p&ci_sign=aec3258277e95af2d39f7db786793b8d33198851)
TEL 5-2423 TRACO POWER
![tel5-datasheet.pdf](/images/adobe-acrobat.png)
Category: DC/DC Converters
Description: Converter: DC/DC; 5W; Uin: 18÷36V; Uout: 15VDC; Uout2: -15VDC; DIP24
Type of converter: DC/DC
Power: 5W
Input voltage: 18...36V
Output voltage: 15V DC
Output voltage 2: -15V DC
Output current: 0.2A
Output current 2: 0.2A
Case: DIP24
Body dimensions: 32x20x10.2mm
Efficiency: 86%
Operating temperature: -40...85°C
Switching frequency: 300kHz
Protection: short circuit protection SCP
Insulation voltage: 1.5kV
Manufacturer series: TEL5
Number of outputs: 2
Anzahl je Verpackung: 1 Stücke
auf Bestellung 7 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl | Preis ohne MwSt |
---|---|
3+ | 24.55 EUR |
4+ | 23.24 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details TEL 5-2423 TRACO POWER
Description: TRACO POWER - TEL 5-2423 - Isolierter DC/DC-Wandler, PCB-Montage, hohe Leistungsdichte, Durchsteckmontage, 5W, 15V, 200mA, -15V, tariffCode: 85044095, DC-Eingangsspannung, min.: 18V, Ausgangsstrom - Ausgang 2: 200mA, rohsCompliant: YES, Höhe: 10.2mm, Nominelle DC-Eingangsspannung: 24V, Tiefe: 31.8mm, hazardous: false, rohsPhthalatesCompliant: YES, Anzahl der Ausgänge: 2 Ausgänge, Breite: 20.3mm, usEccn: EAR99, DC/DC-Wandlerausgang: Fest, Isolationsspannung: 1.5kV, DC-Eingangsspannung, max.: 36V, DC/DC-Wandlermontage: Durchsteckmontage, euEccn: NLR, DC/DC-Wandler: DIP, Ausgangsregelung: Geregelt, Produktpalette: TEL 5 Series, Ausgangsspannung - Ausgang 1: 15V, productTraceability: No, Ausgangsspannung - Ausgang 2: -15V, Ausgangsstrom - Ausgang 1: 200mA, Eingangsverhältnis: 2:1, Anwendungen für das Netzteil: ITE, Ausgangsleistung, max.: 5W, SVHC: No SVHC (14-Jun-2023).
Weitere Produktangebote TEL 5-2423 nach Preis ab 21.59 EUR bis 44.01 EUR
Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis ohne MwSt | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
TEL 5-2423 | Hersteller : TRACO POWER |
![]() Description: Converter: DC/DC; 5W; Uin: 18÷36V; Uout: 15VDC; Uout2: -15VDC; DIP24 Type of converter: DC/DC Power: 5W Input voltage: 18...36V Output voltage: 15V DC Output voltage 2: -15V DC Output current: 0.2A Output current 2: 0.2A Case: DIP24 Body dimensions: 32x20x10.2mm Efficiency: 86% Operating temperature: -40...85°C Switching frequency: 300kHz Protection: short circuit protection SCP Insulation voltage: 1.5kV Manufacturer series: TEL5 Number of outputs: 2 |
auf Bestellung 7 Stücke: Lieferzeit 14-21 Tag (e) |
|
||||||||||
![]() |
TEL 5-2423 | Hersteller : Traco Power |
![]() |
auf Bestellung 114 Stücke: Lieferzeit 14-21 Tag (e) |
|
||||||||||
![]() |
TEL 5-2423 | Hersteller : Traco Power |
![]() |
auf Bestellung 114 Stücke: Lieferzeit 14-21 Tag (e) |
|
||||||||||
![]() |
TEL 5-2423 | Hersteller : Traco Power |
![]() |
auf Bestellung 9 Stücke: Lieferzeit 14-21 Tag (e) |
|
||||||||||
![]() |
TEL 5-2423 | Hersteller : Traco Power |
![]() |
auf Bestellung 30 Stücke: Lieferzeit 14-21 Tag (e) |
|
||||||||||
![]() |
TEL 5-2423 | Hersteller : TRACO Power |
![]() |
auf Bestellung 380 Stücke: Lieferzeit 10-14 Tag (e) |
|
||||||||||
![]() |
TEL 5-2423 | Hersteller : Traco Power |
![]() Features: SCP Packaging: Tube Package / Case: 23-DIP Module, 8 Leads Size / Dimension: 1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm) Mounting Type: Through Hole Type: Isolated Module Operating Temperature: -40°C ~ 85°C (With Derating) Applications: ITE (Commercial) Voltage - Input (Max): 36V Efficiency: 86% Current - Output (Max): 200mA, 200mA Supplier Device Package: Module Voltage - Input (Min): 18V Voltage - Output 1: 15V Voltage - Output 2: -15V Part Status: Active Power (Watts): 6 W Number of Outputs: 2 Voltage - Isolation: 1.5 kV |
auf Bestellung 954 Stücke: Lieferzeit 10-14 Tag (e) |
|
||||||||||
![]() |
TEL 5-2423 | Hersteller : Traco Power |
![]() |
auf Bestellung 7 Stücke: Lieferzeit 14-21 Tag (e) |
|
||||||||||
![]() |
TEL 5-2423 | Hersteller : Traco Power |
![]() |
auf Bestellung 256 Stücke: Lieferzeit 14-21 Tag (e) |
|||||||||||
![]() |
TEL 5-2423 | Hersteller : TRACO POWER |
![]() tariffCode: 85044095 DC-Eingangsspannung, min.: 18V Ausgangsstrom - Ausgang 2: 200mA rohsCompliant: YES Höhe: 10.2mm Nominelle DC-Eingangsspannung: 24V Tiefe: 31.8mm hazardous: false rohsPhthalatesCompliant: YES Anzahl der Ausgänge: 2 Ausgänge Breite: 20.3mm usEccn: EAR99 DC/DC-Wandlerausgang: Fest Isolationsspannung: 1.5kV DC-Eingangsspannung, max.: 36V DC/DC-Wandlermontage: Durchsteckmontage euEccn: NLR DC/DC-Wandler: DIP Ausgangsregelung: Geregelt Produktpalette: TEL 5 Series Ausgangsspannung - Ausgang 1: 15V productTraceability: No Ausgangsspannung - Ausgang 2: -15V Ausgangsstrom - Ausgang 1: 200mA Eingangsverhältnis: 2:1 Anwendungen für das Netzteil: ITE Ausgangsleistung, max.: 5W SVHC: No SVHC (14-Jun-2023) |
auf Bestellung 394 Stücke: Lieferzeit 14-21 Tag (e) |
|||||||||||
TEL5-2423 |
auf Bestellung 6316 Stücke: Lieferzeit 21-28 Tag (e) |
||||||||||||||
TEL 5-2423 | Hersteller : Traco Electronic AG |
![]() |
auf Bestellung 7 Stücke: Lieferzeit 14-21 Tag (e) |
||||||||||||
TEL 5-2423 Produktcode: 31900 |
![]() |
Produkt ist nicht verfügbar
|
