![RDDW20UW-15 RDDW20UW-15](https://mm.digikey.com/Volume0/opasdata/d220001/medias/images/3807/MFG_RSxW20UWseries.jpg)
RDDW20UW-15 MEAN WELL USA Inc.
![RSDW20UW,RDDW20UW-spec.pdf](/images/adobe-acrobat.png)
Description: DC/DC MODULE 20W,I/P:8.5-160VDCO
Features: Remote On/Off
Packaging: Bulk
Package / Case: 6-DIP Module
Size / Dimension: 2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm)
Mounting Type: Through Hole
Type: Isolated Module
Operating Temperature: -40°C ~ 95°C (With Derating)
Applications: ITE (Commercial), Railway
Voltage - Input (Max): 160V
Approval Agency: CE, cURus, EAC, UL
Efficiency: 89%
Current - Output (Max): 667mA, 667mA
Voltage - Input (Min): 8.5V
Voltage - Output 1: 15V
Voltage - Output 2: -15V
Part Status: Active
Power (Watts): 20 W
Number of Outputs: 2
Voltage - Isolation: 3 kV
auf Bestellung 4 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl | Preis ohne MwSt |
---|---|
1+ | 79.09 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details RDDW20UW-15 MEAN WELL USA Inc.
Description: MEAN WELL - RDDW20UW-15 - Isol. DC/DC-Wandler, Durchsteckmontage, Bahnanwendungen, 18:1, 20 W, 2 Ausgänge, 15 V, 667 mA, tariffCode: 85044095, DC-Eingangsspannung, min.: 8.5V, Ausgangsstrom - Ausgang 2: 667mA, rohsCompliant: YES, Höhe: 10.2mm, Nominelle DC-Eingangsspannung: -, Tiefe: 50.8mm, hazardous: false, rohsPhthalatesCompliant: YES, Anzahl der Ausgänge: 2 Ausgänge, Breite: 25.4mm, usEccn: EAR99, DC/DC-Wandlerausgang: Fest, Isolationsspannung: -, DC-Eingangsspannung, max.: 160V, euEccn: NLR, DC/DC-Wandler: DIP, Ausgangsregelung: -, Produktpalette: RDDW20UW Series, Ausgangsspannung - Ausgang 1: 15V, productTraceability: No, Ausgangsspannung - Ausgang 2: -15V, Ausgangsstrom - Ausgang 1: 667mA, Eingangsverhältnis: 18:1, Anwendungen für das Netzteil: Bahnanwendungen, Ausgangsleistung, max.: 20W, SVHC: No SVHC (23-Jan-2024).
Weitere Produktangebote RDDW20UW-15 nach Preis ab 113.73 EUR bis 113.73 EUR
Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis ohne MwSt | ||||
---|---|---|---|---|---|---|---|---|---|
![]() |
RDDW20UW-15 | Hersteller : MEAN WELL |
![]() |
auf Bestellung 6 Stücke: Lieferzeit 10-14 Tag (e) |
|
||||
![]() |
RDDW20UW-15 | Hersteller : MEAN WELL |
![]() tariffCode: 85044095 DC-Eingangsspannung, min.: 8.5V Ausgangsstrom - Ausgang 2: 667mA rohsCompliant: YES Höhe: 10.2mm Nominelle DC-Eingangsspannung: - Tiefe: 50.8mm hazardous: false rohsPhthalatesCompliant: YES Anzahl der Ausgänge: 2 Ausgänge Breite: 25.4mm usEccn: EAR99 DC/DC-Wandlerausgang: Fest Isolationsspannung: - DC-Eingangsspannung, max.: 160V euEccn: NLR DC/DC-Wandler: DIP Ausgangsregelung: - Produktpalette: RDDW20UW Series Ausgangsspannung - Ausgang 1: 15V productTraceability: No Ausgangsspannung - Ausgang 2: -15V Ausgangsstrom - Ausgang 1: 667mA Eingangsverhältnis: 18:1 Anwendungen für das Netzteil: Bahnanwendungen Ausgangsleistung, max.: 20W SVHC: No SVHC (23-Jan-2024) |
auf Bestellung 2 Stücke: Lieferzeit 14-21 Tag (e) |
|||||
RDDW20UW-15 | Hersteller : MEAN WELL |
![]() Description: Converter: DC/DC; 20W; Uin: 8.5÷160V; Uout: 15VDC; Uout2: -15VDC Type of converter: DC/DC Power: 20W Input voltage: 8.5...160V Output voltage: 15V DC Output voltage 2: -15V DC Output current: 0...667mA Output current 2: 0...-667mA Case: 2"x1"; DIP Body dimensions: 50.8x25.4x10.2mm Efficiency: 89% Operating temperature: -40...95°C Switching frequency: 200kHz Protection: anti-overload OLP; anti-overvoltage OVP; short circuit protection SCP Insulation voltage: 3kV DC Mounting: THT Manufacturer series: RDDW20UW Number of outputs: 2 Anzahl je Verpackung: 1 Stücke |
Produkt ist nicht verfügbar |
||||||
RDDW20UW-15 | Hersteller : MEAN WELL |
![]() Description: Converter: DC/DC; 20W; Uin: 8.5÷160V; Uout: 15VDC; Uout2: -15VDC Type of converter: DC/DC Power: 20W Input voltage: 8.5...160V Output voltage: 15V DC Output voltage 2: -15V DC Output current: 0...667mA Output current 2: 0...-667mA Case: 2"x1"; DIP Body dimensions: 50.8x25.4x10.2mm Efficiency: 89% Operating temperature: -40...95°C Switching frequency: 200kHz Protection: anti-overload OLP; anti-overvoltage OVP; short circuit protection SCP Insulation voltage: 3kV DC Mounting: THT Manufacturer series: RDDW20UW Number of outputs: 2 |
Produkt ist nicht verfügbar |
