PI84-230AC-M93G RELPOL
Hersteller: RELPOL
Category: Electromagnetic Relays - Sets
Description: Relay: interface; DPDT; Ucoil: 230VAC; 8A; 8A/230VAC; 8A/24VDC; PI84
Type of relay: interface
Contacts configuration: DPDT
Rated coil voltage: 230V AC
AC contacts rating @R: 8A / 230V AC
DC contacts rating @R: 8A / 24V DC
Relay series: PI84
Switched voltage: max. 300V DC; max. 400V AC
Relay variant: Relay set
Mounting: for DIN rail mounting; on panel
Operate time: 7ms
Body dimensions: 75.5x15.5x67mm
Release time: 3ms
Operating temperature: -40...70°C
Contact resistance: 100mΩ
Switching capacity: 2kVA
Contact material: AgNi
Leads: screw terminals
OEM number: 851989
Max. operating current: 8A
Kit contents: ejector; holder; indication module; label; RM84 relay
Anzahl je Verpackung: 1 Stücke
Category: Electromagnetic Relays - Sets
Description: Relay: interface; DPDT; Ucoil: 230VAC; 8A; 8A/230VAC; 8A/24VDC; PI84
Type of relay: interface
Contacts configuration: DPDT
Rated coil voltage: 230V AC
AC contacts rating @R: 8A / 230V AC
DC contacts rating @R: 8A / 24V DC
Relay series: PI84
Switched voltage: max. 300V DC; max. 400V AC
Relay variant: Relay set
Mounting: for DIN rail mounting; on panel
Operate time: 7ms
Body dimensions: 75.5x15.5x67mm
Release time: 3ms
Operating temperature: -40...70°C
Contact resistance: 100mΩ
Switching capacity: 2kVA
Contact material: AgNi
Leads: screw terminals
OEM number: 851989
Max. operating current: 8A
Kit contents: ejector; holder; indication module; label; RM84 relay
Anzahl je Verpackung: 1 Stücke
auf Bestellung 17 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl | Preis ohne MwSt |
---|---|
5+ | 16.3 EUR |
20+ | 16.2 EUR |
100+ | 15.67 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details PI84-230AC-M93G RELPOL
Category: Electromagnetic Relays - Sets, Description: Relay: interface; DPDT; Ucoil: 230VAC; 8A; 8A/230VAC; 8A/24VDC; PI84, Type of relay: interface, Contacts configuration: DPDT, Rated coil voltage: 230V AC, AC contacts rating @R: 8A / 230V AC, DC contacts rating @R: 8A / 24V DC, Relay series: PI84, Switched voltage: max. 300V DC; max. 400V AC, Relay variant: Relay set, Mounting: for DIN rail mounting; on panel, Operate time: 7ms, Body dimensions: 75.5x15.5x67mm, Release time: 3ms, Operating temperature: -40...70°C, Contact resistance: 100mΩ, Switching capacity: 2kVA, Contact material: AgNi, Leads: screw terminals, OEM number: 851989, Max. operating current: 8A, Kit contents: ejector; holder; indication module; label; RM84 relay, Anzahl je Verpackung: 1 Stücke.
