PF36281B1-000U-A99 SUNON
![PF36281B1-A99_DTE.pdf](/images/adobe-acrobat.png)
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 36x36x28mm; 30.75m3/h; 55.7dBA; ball bearing
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Type of fan: DC
Fan dimensions: 36x36x28mm
Fan motor: brushless DC
Impeller material: thermoplastic
Insulation class: A
Kind of Bearing: ball bearing
Fan efficiency: 30.75m3/h
Static pressure: 41.12mm H2O
Noise level: 55.7dBA
Rotational rate/speed: 18400 (±10%)rpm
Current and power consumption tolerance: ±15%
Power consumption: 5.4W
Wire size: 28AWG
Cable length: 0.14m
Additional functions: autorestart
Storage temperature: -40...80°C
Kind of fan: axial
Min. insulation resistance: 10MΩ
Enclosure material: thermoplastic
Current rating: 0.45A
Supply voltage: 12V DC
Leads: lead x3
Operating voltage: 6...13.2V
Anzahl je Verpackung: 1 Stücke
auf Bestellung 151 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl | Preis ohne MwSt |
---|---|
5+ | 17.52 EUR |
10+ | 15.09 EUR |
50+ | 13.73 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details PF36281B1-000U-A99 SUNON
Category: DC12V Fans, Description: Fan: DC; axial; 12VDC; 36x36x28mm; 30.75m3/h; 55.7dBA; ball bearing, Operating temperature: -10...70°C, Flammability rating: UL94V-0, Type of fan: DC, Fan dimensions: 36x36x28mm, Fan motor: brushless DC, Impeller material: thermoplastic, Insulation class: A, Kind of Bearing: ball bearing, Fan efficiency: 30.75m3/h, Static pressure: 41.12mm H2O, Noise level: 55.7dBA, Rotational rate/speed: 18400 (±10%)rpm, Current and power consumption tolerance: ±15%, Power consumption: 5.4W, Wire size: 28AWG, Cable length: 0.14m, Additional functions: autorestart, Storage temperature: -40...80°C, Kind of fan: axial, Min. insulation resistance: 10MΩ, Enclosure material: thermoplastic, Current rating: 0.45A, Supply voltage: 12V DC, Leads: lead x3, Operating voltage: 6...13.2V, Anzahl je Verpackung: 1 Stücke.
