UT805A UNI-T

Category: Benchtop digital multimeters, Description: Benchtop multimeter; LCD; VDC: 1uV÷200mV,2V,20V,200V,1kV; 230VAC, Type of meter: benchtop multimeter, Measuring instrument features: auto and manual ranging; HOLD function; MIN/MAX/REL function; overflow indication; selection of AC or AC+DC measurement, Kind of display used: LCD, DC voltage measuring range: 1µV...200mV; 2V; 20V; 200V; 1kV, DC voltage measuring accuracy: ±(0,015% + 3 digits), AC voltage measuring range: 1µV...200mV; 2V; 20V; 200V; 750V, AC voltage measuring accuracy: ±(0.2% + 100 digits), AC current measuring range: 0.01µA...2mA; 200mA; 10A, DC current measuring range: 0.01µA...2mA; 200mA; 10A, DC current measuring accuracy: ±(0,05% + 10 digits), AC current measuring accuracy: ±(0,3% + 400 digits), True effective value measurement: True RMS AC, Resistance measuring range: 1mΩ...200Ω; 2kΩ; 20kΩ; 200kΩ; 2MΩ; 20MΩ, Resistance measuring accuracy: ±(0,02% + 6 digit), Capacitance measuring range: 10pF...60nF; 600nF; 6µF; 60µF; 600µF; 6mF, Capacitance measuring accuracy: ±(2% + 5 digits), Frequency measuring range: 1...6kHz; 60kHz; 600kHz; 6MHz; 60MHz, Frequency measuring accuracy: ±(0,1% + 3 digits), Diode test: 0...6V, Continuity test: acoustic indication; .
