![DF1B-26DP-2.5DSA(01) DF1B-26DP-2.5DSA(01)](https://mm.digikey.com/Volume0/opasdata/d220001/medias/images/1074/DF1B-26DP-2.5DSA(01).jpg)
DF1B-26DP-2.5DSA(01) Hirose Electric Co Ltd
![document?clcode=CL0541-0636-1-01&productname=DF1B-18DP-2.5DS(01)&series=DF1B&documenttype=Catalog&lang=en&documentid=D31684_en](/images/adobe-acrobat.png)
Description: CONN HEADER VERT 26POS 2.5MM
Packaging: Bulk
Features: Keying Slot
Connector Type: Header
Voltage Rating: 250V
Mounting Type: Through Hole
Number of Positions: 26
Number of Rows: 2
Style: Board to Cable/Wire
Operating Temperature: -35°C ~ 85°C
Contact Type: Male Pin
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Brass
Insulation Color: White
Pitch - Mating: 0.098" (2.50mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 8.00µin (0.203µm)
Part Status: Active
Contact Shape: Square
Contact Length - Post: 0.142" (3.60mm)
Insulation Height: 0.374" (9.50mm)
Shrouding: Shrouded - 4 Wall
Overall Contact Length: 0.417" (10.60mm)
Insulation Material: Polyamide (PA), Nylon
Row Spacing - Mating: 0.098" (2.50mm)
Contact Length - Mating: 0.177" (4.50mm)
auf Bestellung 200 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl | Preis ohne MwSt |
---|---|
6+ | 3.24 EUR |
10+ | 2.82 EUR |
100+ | 2.52 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details DF1B-26DP-2.5DSA(01) Hirose Electric Co Ltd
Description: CONN HEADER VERT 26POS 2.5MM, Packaging: Bulk, Features: Keying Slot, Connector Type: Header, Voltage Rating: 250V, Mounting Type: Through Hole, Number of Positions: 26, Number of Rows: 2, Style: Board to Cable/Wire, Operating Temperature: -35°C ~ 85°C, Contact Type: Male Pin, Fastening Type: Push-Pull, Number of Positions Loaded: All, Termination: Solder, Material Flammability Rating: UL94 V-0, Contact Material: Brass, Insulation Color: White, Pitch - Mating: 0.098" (2.50mm), Contact Finish - Mating: Gold, Contact Finish Thickness - Mating: 8.00µin (0.203µm), Part Status: Active, Contact Shape: Square, Contact Length - Post: 0.142" (3.60mm), Insulation Height: 0.374" (9.50mm), Shrouding: Shrouded - 4 Wall, Overall Contact Length: 0.417" (10.60mm), Insulation Material: Polyamide (PA), Nylon, Row Spacing - Mating: 0.098" (2.50mm), Contact Length - Mating: 0.177" (4.50mm).
Weitere Produktangebote DF1B-26DP-2.5DSA(01) nach Preis ab 1.04 EUR bis 1.57 EUR
