![8-1393243-2 8-1393243-2](https://ce8dc832c.cloudimg.io/v7/_cdn_/E5/A6/60/00/0/420446_1.jpg?width=640&height=480&wat=1&wat_url=_tme-wrk_%2Ftme_new.png&wat_scale=100p&ci_sign=7169a57f3a01d1a9291fd15fc3a811b7ebfa332a)
8-1393243-2 TE Connectivity
![RT2_1014.pdf](/images/adobe-acrobat.png)
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 8A; 8A/250VAC; 8A/30VDC
Number of pins: 8
Contact current max.: 8A
Height: 15.7mm
Related items: RT17017; RT17040; RT78726
Mounting: PCB
Relay series: RT2
Operating temperature: -40...70°C
IP rating: IP40
Body dimensions: 29x12.7x15.7mm
AC contacts rating @R: 8A / 250V AC
DC contacts rating @R: 8A / 30V DC
Switched voltage: max. 300V DC; max. 400V AC
Terminal pitch: 5mm
Rated coil voltage: 12V DC
Type of relay: electromagnetic
Contacts configuration: DPDT
Relay variant: miniature
Coil power consumption: 400mW
Operate time: 7ms
Release time: 2ms
Contact material: AgNi 90/10
Coil voltage min.: 8.4V DC
Coil resistance: 360Ω
Anzahl je Verpackung: 1 Stücke
auf Bestellung 253 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl | Preis ohne MwSt |
---|---|
8+ | 8.97 EUR |
12+ | 5.99 EUR |
500+ | 5.76 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details 8-1393243-2 TE Connectivity
Category: Miniature Electromagnetic Relays, Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 8A; 8A/250VAC; 8A/30VDC, Number of pins: 8, Contact current max.: 8A, Height: 15.7mm, Related items: RT17017; RT17040; RT78726, Mounting: PCB, Relay series: RT2, Operating temperature: -40...70°C, IP rating: IP40, Body dimensions: 29x12.7x15.7mm, AC contacts rating @R: 8A / 250V AC, DC contacts rating @R: 8A / 30V DC, Switched voltage: max. 300V DC; max. 400V AC, Terminal pitch: 5mm, Rated coil voltage: 12V DC, Type of relay: electromagnetic, Contacts configuration: DPDT, Relay variant: miniature, Coil power consumption: 400mW, Operate time: 7ms, Release time: 2ms, Contact material: AgNi 90/10, Coil voltage min.: 8.4V DC, Coil resistance: 360Ω, Anzahl je Verpackung: 1 Stücke.
Weitere Produktangebote 8-1393243-2 nach Preis ab 4.8 EUR bis 15.72 EUR
Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis ohne MwSt | ||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
8-1393243-2 | Hersteller : TE Connectivity |
![]() Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 8A; 8A/250VAC; 8A/30VDC Number of pins: 8 Contact current max.: 8A Height: 15.7mm Related items: RT17017; RT17040; RT78726 Mounting: PCB Relay series: RT2 Operating temperature: -40...70°C IP rating: IP40 Body dimensions: 29x12.7x15.7mm AC contacts rating @R: 8A / 250V AC DC contacts rating @R: 8A / 30V DC Switched voltage: max. 300V DC; max. 400V AC Terminal pitch: 5mm Rated coil voltage: 12V DC Type of relay: electromagnetic Contacts configuration: DPDT Relay variant: miniature Coil power consumption: 400mW Operate time: 7ms Release time: 2ms Contact material: AgNi 90/10 Coil voltage min.: 8.4V DC Coil resistance: 360Ω |
auf Bestellung 253 Stücke: Lieferzeit 14-21 Tag (e) |
|
||||||||||||||
![]() |
8-1393243-2 | Hersteller : TE Connectivity |
![]() |
auf Bestellung 6337 Stücke: Lieferzeit 14-21 Tag (e) |
|
||||||||||||||
![]() |
8-1393243-2 | Hersteller : TE Connectivity |
![]() |
auf Bestellung 6337 Stücke: Lieferzeit 14-21 Tag (e) |
|
||||||||||||||
![]() |
8-1393243-2 | Hersteller : TE Connectivity |
![]() |
auf Bestellung 76 Stücke: Lieferzeit 14-21 Tag (e) |
|
||||||||||||||
![]() |
8-1393243-2 | Hersteller : TE Connectivity |
![]() |
auf Bestellung 372 Stücke: Lieferzeit 14-21 Tag (e) |
|
||||||||||||||
![]() |
8-1393243-2 | Hersteller : SCHRACK - TE CONNECTIVITY |
Description: SCHRACK - TE CONNECTIVITY - 8-1393243-2 - Universelles Leistungsrelais, Baureihe RT2, monostabil, DPDT, 12V DC, 8A tariffCode: 85364190 rohsCompliant: YES Zulassungen & Normen: CSA, UL, VDE Relaisanschlüsse: Lötanschlüsse hazardous: false rohsPhthalatesCompliant: YES Spulentyp: Monostabil Kontaktmaterial: Silber-Nickel Kontaktstrom: 8A usEccn: EAR99 Spulenwiderstand: 360ohm euEccn: NLR Kontaktspannung V DC: - Relaismontage: Durchsteckmontage Produktpalette: RT2 productTraceability: No Spulenspannung: 12VDC Kontaktkonfiguration: DPDT Kontaktspannung V AC: 250VAC SVHC: No SVHC (23-Jan-2024) |
auf Bestellung 571 Stücke: Lieferzeit 14-21 Tag (e) |
|||||||||||||||
![]() |
8-1393243-2 | Hersteller : TE Connectivity |
![]() |
auf Bestellung 24521 Stücke: Lieferzeit 14-21 Tag (e) |
