10027843 FISCHER ELEKTRONIK
Hersteller: FISCHER ELEKTRONIK
Category: Pin headers
Description: Connector: pin strips; socket; female; PIN: 6; straight; 2mm; SMT
Operating temperature: -40...163°C
Rated voltage: 100V
Number of pins: 6
Contact material: beryllium copper
Connector pinout layout: 2x3
Contacts pitch: 2mm
Electrical mounting: SMT
Row pitch: 2mm
Plating thickness: 0.254µm
Spatial orientation: straight
Type of connector: pin strips
Connector: socket
Kind of connector: female
Contact plating: gold-plated
Current rating: 2.5A
Flammability rating: UL94V-0
Anzahl je Verpackung: 1 Stücke
Category: Pin headers
Description: Connector: pin strips; socket; female; PIN: 6; straight; 2mm; SMT
Operating temperature: -40...163°C
Rated voltage: 100V
Number of pins: 6
Contact material: beryllium copper
Connector pinout layout: 2x3
Contacts pitch: 2mm
Electrical mounting: SMT
Row pitch: 2mm
Plating thickness: 0.254µm
Spatial orientation: straight
Type of connector: pin strips
Connector: socket
Kind of connector: female
Contact plating: gold-plated
Current rating: 2.5A
Flammability rating: UL94V-0
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Produktrezensionen
Produktbewertung abgeben
Technische Details 10027843 FISCHER ELEKTRONIK
Category: Pin headers, Description: Connector: pin strips; socket; female; PIN: 6; straight; 2mm; SMT, Operating temperature: -40...163°C, Rated voltage: 100V, Number of pins: 6, Contact material: beryllium copper, Connector pinout layout: 2x3, Contacts pitch: 2mm, Electrical mounting: SMT, Row pitch: 2mm, Plating thickness: 0.254µm, Spatial orientation: straight, Type of connector: pin strips, Connector: socket, Kind of connector: female, Contact plating: gold-plated, Current rating: 2.5A, Flammability rating: UL94V-0, Anzahl je Verpackung: 1 Stücke.
