Produkte > SANYO DENKI > Alle Produkte des Herstellers SANYO DENKI (8159) > Seite 77 nach 136

Wählen Sie Seite:   [  << Vorherige Seite ]  1 13 26 39 52 65 72 73 74 75 76 77 78 79 80 81 82 91 104 117 130 136  [ Nächste Seite >> ]
Foto Bezeichnung Hersteller Beschreibung Verfügbarkeit
Preis
ohne MwSt
109P0412E601 SANYO DENKI 109P0412E601.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x20mm; 15.6m3/h; 37dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 7...13.8V
Fan dimensions: 40x40x20mm
Power consumption: 1.56W
Current rating: 0.13A
Fan efficiency: 15.6m3/h
Noise level: 37dBA
Kind of Bearing: ball
Rotational rate/speed: 9200rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412F301 SANYO DENKI San_Ace_E.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 14.64m3/h; 30dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 7...13.8V
Fan dimensions: 40x40x28mm
Power consumption: 1.26W
Current rating: 0.105A
Fan efficiency: 14.64m3/h
Noise level: 30dBA
Kind of Bearing: ball
Rotational rate/speed: 6700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412F3013 109P0412F3013 SANYO DENKI 109P0412F3013.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 14.64m3/h; 30dBA; ball; 6700rpm
Power consumption: 1.26W
Supply voltage: 12V DC
Current rating: 0.105A
Operating temperature: -20...70°C
Additional functions: lock sensor; reverse polarity protection
Cable length: 0.32m
Rotational rate/speed: 6700rpm
Leads: lead x3
Operating voltage: 7...13.8V
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Type of fan: DC
Fan dimensions: 40x40x28mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 14.64m3/h
Noise level: 30dBA
Kind of fan: axial
Anzahl je Verpackung: 1 Stücke
auf Bestellung 217 Stücke:
Lieferzeit 7-14 Tag (e)
6+13.13 EUR
10+ 12.66 EUR
20+ 12.34 EUR
Mindestbestellmenge: 6
109P0412F302 SANYO DENKI San_Ace_E.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 14.64m3/h; 30dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 7...13.8V
Fan dimensions: 40x40x28mm
Power consumption: 1.26W
Current rating: 0.105A
Fan efficiency: 14.64m3/h
Noise level: 30dBA
Kind of Bearing: ball
Rotational rate/speed: 6700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412G302 SANYO DENKI San_Ace_E.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 25.2m3/h; 42dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 7...13.2V
Fan dimensions: 40x40x28mm
Power consumption: 3.72W
Current rating: 0.31A
Fan efficiency: 25.2m3/h
Noise level: 42dBA
Kind of Bearing: ball
Rotational rate/speed: 11500rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...60°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412G3D01 SANYO DENKI San_Ace_E.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 25.2m3/h; 42dBA; ball bearing
Operating voltage: 7...13.2V
Supply voltage: 12V DC
Additional functions: lock sensor; reverse polarity protection
Enclosure material: plastic
Current rating: 0.31A
Leads: lead x3
Type of fan: DC
Fan dimensions: 40x40x28mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 25.2m3/h
Noise level: 42dBA
Rotational rate/speed: 11500rpm
Power consumption: 3.72W
Cable length: 0.32m
Kind of fan: axial
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Operating temperature: -20...60°C
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412H301 109P0412H301 SANYO DENKI San_Ace_E.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 19.2m3/h; 37dBA; ball; 8700rpm
Power consumption: 2.34W
Supply voltage: 12V DC
Current rating: 0.195A
Operating temperature: -20...70°C
Additional functions: lock sensor; reverse polarity protection
Cable length: 0.32m
Rotational rate/speed: 8700rpm
Leads: lead x3
Operating voltage: 7...13.8V
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Type of fan: DC
Fan dimensions: 40x40x28mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 19.2m3/h
Noise level: 37dBA
Kind of fan: axial
Anzahl je Verpackung: 1 Stücke
auf Bestellung 37 Stücke:
Lieferzeit 7-14 Tag (e)
4+18.88 EUR
5+ 14.6 EUR
50+ 13.57 EUR
Mindestbestellmenge: 4
109P0412H3013 SANYO DENKI 109P0412H3013.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 19.2m3/h; 37dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 7...13.8V
Fan dimensions: 40x40x28mm
Power consumption: 2.34W
Current rating: 0.195A
Fan efficiency: 19.2m3/h
Noise level: 37dBA
Kind of Bearing: ball
Rotational rate/speed: 8700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412H302 SANYO DENKI San_Ace_E.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 19.2m3/h; 37dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 7...13.8V
Fan dimensions: 40x40x28mm
Power consumption: 2.34W
Current rating: 0.195A
Fan efficiency: 19.2m3/h
Noise level: 37dBA
Kind of Bearing: ball
Rotational rate/speed: 8700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412H3023 SANYO DENKI San_Ace_E.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 19.2m3/h; 37dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 7...13.8V
Fan dimensions: 40x40x28mm
Power consumption: 2.34W
Current rating: 0.195A
Fan efficiency: 19.2m3/h
Noise level: 37dBA
Kind of Bearing: ball
Rotational rate/speed: 8700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412H3D01 SANYO DENKI San_Ace_E.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 19.2m3/h; 37dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 7...13.8V
Fan dimensions: 40x40x28mm
Power consumption: 2.34W
Current rating: 0.195A
Fan efficiency: 19.2m3/h
Noise level: 37dBA
Kind of Bearing: ball
Rotational rate/speed: 8700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412H601 SANYO DENKI 109P0412H601.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x20mm; 13.5m3/h; 33dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 7...13.8V
Fan dimensions: 40x40x20mm
Power consumption: 1.32W
Current rating: 0.11A
Fan efficiency: 13.5m3/h
Noise level: 33dBA
Kind of Bearing: ball
Rotational rate/speed: 8000rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412H701 109P0412H701 SANYO DENKI 109P0412H701.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x15mm; 10.8m3/h; 28dBA; ball; 7700rpm
Power consumption: 1.56W
Supply voltage: 12V DC
Current rating: 0.13A
Operating temperature: -20...70°C
Additional functions: lock sensor; reverse polarity protection
Cable length: 0.32m
Rotational rate/speed: 7700rpm
Leads: lead x3
Operating voltage: 10.2...13.8V
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Type of fan: DC
Fan dimensions: 40x40x15mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 10.8m3/h
Noise level: 28dBA
Kind of fan: axial
Anzahl je Verpackung: 1 Stücke
auf Bestellung 148 Stücke:
Lieferzeit 7-14 Tag (e)
7+11.8 EUR
10+ 11.37 EUR
20+ 11.08 EUR
Mindestbestellmenge: 7
109P0412H702 SANYO DENKI San_Ace_E.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x15mm; 10.8m3/h; 28dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 10.2...13.8V
Fan dimensions: 40x40x15mm
Power consumption: 1.56W
Current rating: 0.13A
Fan efficiency: 10.8m3/h
Noise level: 28dBA
Kind of Bearing: ball
Rotational rate/speed: 7700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412H901 109P0412H901 SANYO DENKI 109P0412H901.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x10mm; 9m3/h; 25dBA; ball; 6200rpm
Power consumption: 0.84W
Supply voltage: 12V DC
Current rating: 70mA
Operating temperature: -10...60°C
Additional functions: lock sensor; reverse polarity protection
Cable length: 0.32m
Rotational rate/speed: 6200rpm
Leads: lead x3
Operating voltage: 7...13.8V
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Type of fan: DC
Fan dimensions: 40x40x10mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 9m3/h
Noise level: 25dBA
Kind of fan: axial
Anzahl je Verpackung: 1 Stücke
auf Bestellung 84 Stücke:
Lieferzeit 7-14 Tag (e)
6+12.47 EUR
10+ 12.03 EUR
20+ 11.71 EUR
Mindestbestellmenge: 6
109P0412J301 SANYO DENKI San_Ace_E.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 27.6m3/h; 44dBA; ball; 12500rpm
Operating temperature: -20...60°C
Operating voltage: 7...13.8V
Flammability rating: UL94V-1
Kind of material: flame retardant
Leads: lead x3
Enclosure material: plastic
Type of fan: DC
Fan dimensions: 40x40x28mm
Impeller material: plastic
Min. insulation resistance: 10MΩ
Kind of Bearing: ball
Fan efficiency: 27.6m3/h
Noise level: 44dBA
Rotational rate/speed: 12500rpm
Power consumption: 4.2W
Cable length: 0.32m
Additional functions: lock sensor; reverse polarity protection
Kind of fan: axial
Current rating: 0.35A
Supply voltage: 12V DC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412J3023 SANYO DENKI San_Ace_E.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 27.6m3/h; 44dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 7...13.8V
Fan dimensions: 40x40x28mm
Power consumption: 4.2W
Current rating: 0.35A
Fan efficiency: 27.6m3/h
Noise level: 44dBA
Kind of Bearing: ball
Rotational rate/speed: 12500rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...60°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412K301 SANYO DENKI San_Ace_E.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 35.4m3/h; 50dBA; ball bearing
Operating temperature: -20...70°C
Operating voltage: 8...13.2V
Type of fan: DC
Fan dimensions: 40x40x28mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 35.4m3/h
Noise level: 50dBA
Rotational rate/speed: 15500rpm
Power consumption: 6.6W
Cable length: 0.32m
Additional functions: lock sensor; reverse polarity protection
Kind of fan: axial
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Current rating: 0.55A
Supply voltage: 12V DC
Leads: lead x3
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412K3013 109P0412K3013 SANYO DENKI 109P0412K3013.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 35.4m3/h; 50dBA; ball bearing
Operating temperature: -20...70°C
Operating voltage: 8...13.2V
Type of fan: DC
Fan dimensions: 40x40x28mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 35.4m3/h
Noise level: 50dBA
Rotational rate/speed: 15500rpm
Power consumption: 6.6W
Cable length: 0.32m
Additional functions: lock sensor; reverse polarity protection
Kind of fan: axial
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Current rating: 0.55A
Supply voltage: 12V DC
Leads: lead x3
Anzahl je Verpackung: 1 Stücke
auf Bestellung 269 Stücke:
Lieferzeit 7-14 Tag (e)
6+14.13 EUR
10+ 13.57 EUR
20+ 13.23 EUR
Mindestbestellmenge: 6
109P0412K3023 109P0412K3023 SANYO DENKI TR16e_e_en.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 35.4m3/h; 50dBA; ball; 15500rpm
Current rating: 0.55A
Supply voltage: 12V DC
Leads: lead x2
Operating voltage: 8...13.2V
Type of fan: DC
Fan dimensions: 40x40x28mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 35.4m3/h
Noise level: 50dBA
Rotational rate/speed: 15500rpm
Power consumption: 6.6W
Cable length: 0.32m
Additional functions: lock sensor; reverse polarity protection
Kind of fan: axial
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Operating temperature: -20...70°C
Enclosure material: plastic
Anzahl je Verpackung: 1 Stücke
auf Bestellung 304 Stücke:
Lieferzeit 7-14 Tag (e)
6+12.48 EUR
10+ 12.04 EUR
20+ 11.78 EUR
Mindestbestellmenge: 6
109P0412K3D013 SANYO DENKI San_Ace_E.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 35.4m3/h; 50dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 8...13.2V
Fan dimensions: 40x40x28mm
Power consumption: 6.6W
Current rating: 550mA
Fan efficiency: 35.4m3/h
Noise level: 50dBA
Kind of Bearing: ball
Rotational rate/speed: 15500rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412M302 SANYO DENKI San_Ace_E.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 9m3/h; 20dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 10.2...13.8V
Fan dimensions: 40x40x28mm
Power consumption: 0.54W
Current rating: 45mA
Fan efficiency: 9m3/h
Noise level: 20dBA
Kind of Bearing: ball
Rotational rate/speed: 4100rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412M602 SANYO DENKI San_Ace_E.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x20mm; 8.16m3/h; 24dBA; ball; 5000rpm
Supply voltage: 12V DC
Leads: lead x3
Operating voltage: 8...13.8V
Type of fan: DC
Fan dimensions: 40x40x20mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 8.16m3/h
Noise level: 24dBA
Rotational rate/speed: 5000rpm
Power consumption: 0.72W
Cable length: 0.32m
Additional functions: lock sensor; reverse polarity protection
Kind of fan: axial
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Operating temperature: -20...70°C
Enclosure material: plastic
Current rating: 60mA
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412M701 109P0412M701 SANYO DENKI 109P0412M701.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x15mm; 9m3/h; 24dBA; ball; 6500rpm
Operating temperature: -20...70°C
Type of fan: DC
Fan dimensions: 40x40x15mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 9m3/h
Noise level: 24dBA
Rotational rate/speed: 6500rpm
Power consumption: 1.14W
Cable length: 0.32m
Additional functions: lock sensor; reverse polarity protection
Kind of fan: axial
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Current rating: 95mA
Supply voltage: 12V DC
Leads: lead x3
Operating voltage: 10.2...13.8V
Anzahl je Verpackung: 1 Stücke
auf Bestellung 320 Stücke:
Lieferzeit 7-14 Tag (e)
7+10.94 EUR
10+ 10.54 EUR
20+ 10.28 EUR
Mindestbestellmenge: 7
109P0412M702 SANYO DENKI San_Ace_E.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x15mm; 9m3/h; 24dBA; ball bearing
Operating temperature: -20...70°C
Leads: lead x3
Supply voltage: 12V DC
Current rating: 95mA
Additional functions: lock sensor; reverse polarity protection
Power consumption: 1.14W
Cable length: 0.32m
Kind of fan: axial
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Operating voltage: 10.2...13.8V
Type of fan: DC
Fan dimensions: 40x40x15mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 9m3/h
Noise level: 24dBA
Rotational rate/speed: 6500rpm
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412P3H013 109P0412P3H013 SANYO DENKI San_Ace_E.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 19.2m3/h; 37dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 7...13.8V
Fan dimensions: 40x40x28mm
Power consumption: 2.34W
Current rating: 0.195A
Fan efficiency: 19.2m3/h
Noise level: 37dBA
Kind of Bearing: ball
Rotational rate/speed: 8700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x4
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; PWM; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
auf Bestellung 41 Stücke:
Lieferzeit 7-14 Tag (e)
5+14.67 EUR
10+ 14.13 EUR
20+ 13.73 EUR
Mindestbestellmenge: 5
109P0412S701 SANYO DENKI 109P0412S701.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x15mm; 12m3/h; 32dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 10.2...13.8V
Fan dimensions: 40x40x15mm
Power consumption: 2.16W
Current rating: 0.18A
Fan efficiency: 12m3/h
Noise level: 32dBA
Kind of Bearing: ball
Rotational rate/speed: 8600rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412S702 SANYO DENKI San_Ace_E.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x15mm; 12m3/h; 32dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 10.2...13.8V
Fan dimensions: 40x40x15mm
Power consumption: 2.16W
Current rating: 0.18A
Fan efficiency: 12m3/h
Noise level: 32dBA
Kind of Bearing: ball
Rotational rate/speed: 8600rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424B302 SANYO DENKI San_Ace_E.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x28mm; 22.8m3/h; 40dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 12...26.4V
Fan dimensions: 40x40x28mm
Power consumption: 3.12W
Current rating: 0.13A
Fan efficiency: 22.8m3/h
Noise level: 40dBA
Kind of Bearing: ball
Rotational rate/speed: 10300rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...60°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424B602 SANYO DENKI San_Ace_E.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x20mm; 8.4m3/h; 25dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 20.4...27.6V
Fan dimensions: 40x40x20mm
Power consumption: 1.44W
Current rating: 60mA
Fan efficiency: 8.4m3/h
Noise level: 25dBA
Kind of Bearing: ball
Rotational rate/speed: 5200rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424D601 SANYO DENKI 109P0424D601.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x20mm; 18.6m3/h; 42dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 12...27.6V
Fan dimensions: 40x40x20mm
Power consumption: 3.12W
Current rating: 0.13A
Fan efficiency: 18.6m3/h
Noise level: 42dBA
Kind of Bearing: ball
Rotational rate/speed: 11000rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...60°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
auf Bestellung 64 Stücke:
Lieferzeit 7-14 Tag (e)
4+19.02 EUR
5+ 15.03 EUR
6+ 14.24 EUR
Mindestbestellmenge: 4
109P0424D6D01 SANYO DENKI San_Ace_E.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x20mm; 18.6m3/h; 42dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 12...27.6V
Fan dimensions: 40x40x20mm
Power consumption: 3.12W
Current rating: 0.13A
Fan efficiency: 18.6m3/h
Noise level: 42dBA
Kind of Bearing: ball
Rotational rate/speed: 11000rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...60°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424F302 SANYO DENKI San_Ace_E.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x28mm; 14.64m3/h; 30dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 14...27.6V
Fan dimensions: 40x40x28mm
Power consumption: 1.32W
Current rating: 55mA
Fan efficiency: 14.64m3/h
Noise level: 30dBA
Kind of Bearing: ball
Rotational rate/speed: 6700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424F3023 SANYO DENKI San_Ace_E.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x28mm; 14.64m3/h; 30dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 14...27.6V
Fan dimensions: 40x40x28mm
Power consumption: 1.32W
Current rating: 55mA
Fan efficiency: 14.64m3/h
Noise level: 30dBA
Kind of Bearing: ball
Rotational rate/speed: 6700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424F602 SANYO DENKI San_Ace_E.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x20mm; 10.98m3/h; 28dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 14...27.6V
Fan dimensions: 40x40x20mm
Power consumption: 1.44W
Current rating: 60mA
Fan efficiency: 10.98m3/h
Noise level: 28dBA
Kind of Bearing: ball
Rotational rate/speed: 6500rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424G301 SANYO DENKI San_Ace_E.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x28mm; 25.8m3/h; 42dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 12...26.4V
Fan dimensions: 40x40x28mm
Power consumption: 4.56W
Current rating: 0.19A
Fan efficiency: 25.8m3/h
Noise level: 42dBA
Kind of Bearing: ball
Rotational rate/speed: 11500rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...60°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424G3013 SANYO DENKI 109P0424G3013.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x28mm; 25.8m3/h; 42dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 12...26.4V
Fan dimensions: 40x40x28mm
Power consumption: 4.56W
Current rating: 0.19A
Fan efficiency: 25.8m3/h
Noise level: 42dBA
Kind of Bearing: ball
Rotational rate/speed: 11500rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...60°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424G3023 109P0424G3023 SANYO DENKI San_Ace_E.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x28mm; 25.8m3/h; 42dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 12...26.4V
Fan dimensions: 40x40x28mm
Power consumption: 4.56W
Current rating: 0.19A
Fan efficiency: 25.8m3/h
Noise level: 42dBA
Kind of Bearing: ball
Rotational rate/speed: 11500rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...60°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424H301 109P0424H301 SANYO DENKI San_Ace_E.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x28mm; 19.2m3/h; 37dBA; ball; 8700rpm
Power consumption: 2.28W
Supply voltage: 24V DC
Current rating: 95mA
Operating temperature: -20...70°C
Additional functions: lock sensor; reverse polarity protection
Cable length: 0.32m
Rotational rate/speed: 8700rpm
Leads: lead x3
Operating voltage: 12...27.6V
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Type of fan: DC
Fan dimensions: 40x40x28mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 19.2m3/h
Noise level: 37dBA
Kind of fan: axial
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424H302 SANYO DENKI San_Ace_E.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x28mm; 19.2m3/h; 37dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 12...27.6V
Fan dimensions: 40x40x28mm
Power consumption: 2.28W
Current rating: 95mA
Fan efficiency: 19.2m3/h
Noise level: 37dBA
Kind of Bearing: ball
Rotational rate/speed: 8700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424H3023 SANYO DENKI San_Ace_E.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x28mm; 19.2m3/h; 37dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 12...27.6V
Fan dimensions: 40x40x28mm
Power consumption: 2.28W
Current rating: 95mA
Fan efficiency: 19.2m3/h
Noise level: 37dBA
Kind of Bearing: ball
Rotational rate/speed: 8700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424H3D01 109P0424H3D01 SANYO DENKI San_Ace_E.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x28mm; 19.2m3/h; 37dBA; ball; 8700rpm
Power consumption: 2.28W
Supply voltage: 24V DC
Current rating: 95mA
Operating temperature: -20...70°C
Additional functions: lock sensor; reverse polarity protection
Cable length: 0.32m
Rotational rate/speed: 8700rpm
Leads: lead x3
Operating voltage: 12...27.6V
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Type of fan: DC
Fan dimensions: 40x40x28mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 19.2m3/h
Noise level: 37dBA
Kind of fan: axial
Anzahl je Verpackung: 1 Stücke
auf Bestellung 240 Stücke:
Lieferzeit 7-14 Tag (e)
6+13.86 EUR
10+ 13.4 EUR
20+ 13.06 EUR
Mindestbestellmenge: 6
109P0424H602 109P0424H602 SANYO DENKI San_Ace_E.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x20mm; 19.2m3/h; 37dBA; ball; 8700rpm
Power consumption: 2.28W
Supply voltage: 24V DC
Current rating: 95mA
Operating temperature: -20...70°C
Additional functions: lock sensor; reverse polarity protection
Cable length: 0.32m
Rotational rate/speed: 8700rpm
Leads: lead x2
Operating voltage: 12...27.6V
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Type of fan: DC
Fan dimensions: 40x40x20mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 19.2m3/h
Noise level: 37dBA
Kind of fan: axial
Anzahl je Verpackung: 1 Stücke
auf Bestellung 19 Stücke:
Lieferzeit 7-14 Tag (e)
5+14.83 EUR
6+ 14.04 EUR
10+ 13.86 EUR
50+ 13.18 EUR
Mindestbestellmenge: 5
109P0424H6D01 109P0424H6D01 SANYO DENKI San_Ace_E.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x20mm; 13.98m3/h; 35dBA; ball; 8300rpm
Power consumption: 1.68W
Supply voltage: 24V DC
Current rating: 70mA
Operating temperature: -10...70°C
Cable length: 0.3m
Rotational rate/speed: 8300rpm
Leads: lead x3
Operating voltage: 12...27.6V
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Type of fan: DC
Fan dimensions: 40x40x20mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Kind of Bearing: ball
Fan efficiency: 13.98m3/h
Static pressure: 7.11mm H2O
Noise level: 35dBA
Wire size: 24AWG
Kind of fan: axial
Anzahl je Verpackung: 1 Stücke
auf Bestellung 254 Stücke:
Lieferzeit 7-14 Tag (e)
5+14.53 EUR
10+ 13.91 EUR
20+ 13.6 EUR
50+ 13.57 EUR
Mindestbestellmenge: 5
109P0424H7D01 SANYO DENKI San_Ace_E.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 52x52x15mm; 13.38m3/h; 35dBA; ball bearing
Cable length: 0.32m
Fan efficiency: 13.38m3/h
Operating temperature: -20...70°C
Rotational rate/speed: 8300rpm
Enclosure material: plastic
Kind of Bearing: ball
Leads: lead x3
Fan dimensions: 52x52x15mm
Min. insulation resistance: 10MΩ
Kind of material: flame retardant
Power consumption: 1.68W
Impeller material: plastic
Type of fan: DC
Noise level: 35dBA
Additional functions: lock sensor; reverse polarity protection
Operating voltage: 12...27.6V
Kind of fan: axial
Supply voltage: 24V DC
Flammability rating: UL94V-1
Current rating: 70mA
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424J3023 109P0424J3023 SANYO DENKI San_Ace_E.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x28mm; 27.6m3/h; 44dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 12...26.4V
Fan dimensions: 40x40x28mm
Power consumption: 4.32W
Current rating: 0.18A
Fan efficiency: 27.6m3/h
Noise level: 44dBA
Kind of Bearing: ball
Rotational rate/speed: 12500rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x2
Operating temperature: -20...60°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424J3D013 SANYO DENKI page=40P28 109P0424J3D013 DC24V Fans
Produkt ist nicht verfügbar
109P0424R3013 109P0424R3013 SANYO DENKI 109P0424R3013.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x28mm; 30.6m3/h; 47dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 12...26.4V
Fan dimensions: 40x40x28mm
Power consumption: 6W
Current rating: 0.25A
Fan efficiency: 30.6m3/h
Noise level: 47dBA
Kind of Bearing: ball
Rotational rate/speed: 14000rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...60°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0505M701 SANYO DENKI 109P0505M701.pdf Category: DC5V Fans
Description: Fan: DC; axial; 5VDC; 52x52x15mm; 12.3m3/h; 22dBA; ball bearing
Leads: lead x3
Operating voltage: 4.5...5.5V
Type of fan: DC
Fan dimensions: 52x52x15mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 12.3m3/h
Noise level: 22dBA
Rotational rate/speed: 3700rpm
Power consumption: 0.75W
Cable length: 0.3m
Additional functions: lock sensor; reverse polarity protection
Kind of fan: axial
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Operating temperature: -20...70°C
Enclosure material: plastic
Current rating: 0.15A
Supply voltage: 5V DC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0512A701 SANYO DENKI 109P0512A701.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 52x52x15mm; 22.5m3/h; 36dBA; ball bearing
Enclosure material: plastic
Current rating: 0.21A
Operating temperature: -20...70°C
Supply voltage: 12V DC
Leads: lead x3
Operating voltage: 10.2...13.8V
Type of fan: DC
Fan dimensions: 52x52x15mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 22.5m3/h
Noise level: 36dBA
Rotational rate/speed: 6800rpm
Power consumption: 2.52W
Cable length: 0.3m
Additional functions: lock sensor; reverse polarity protection
Kind of fan: axial
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0512A702 SANYO DENKI 109P0512A702.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 52x52x15mm; 22.5m3/h; 36dBA; ball; 6800rpm
Supply voltage: 12V DC
Operating temperature: -20...70°C
Leads: lead x3
Cable length: 0.3m
Operating voltage: 10.2...13.8V
Additional functions: lock sensor; reverse polarity protection
Enclosure material: plastic
Current rating: 0.21A
Kind of material: flame retardant
Type of fan: DC
Min. insulation resistance: 10MΩ
Kind of fan: axial
Fan efficiency: 22.5m3/h
Noise level: 36dBA
Rotational rate/speed: 6800rpm
Kind of Bearing: ball
Power consumption: 2.52W
Flammability rating: UL94V-1
Impeller material: plastic
Fan dimensions: 52x52x15mm
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0512H702 SANYO DENKI 109P0512H702.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 52x52x15mm; 15.3m3/h; 27dBA; ball bearing
Operating temperature: -20...70°C
Supply voltage: 12V DC
Cable length: 0.3m
Power consumption: 1.2W
Additional functions: lock sensor; reverse polarity protection
Kind of fan: axial
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Current rating: 0.1A
Leads: lead x3
Operating voltage: 7...13.8V
Type of fan: DC
Fan dimensions: 52x52x15mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 15.3m3/h
Noise level: 27dBA
Rotational rate/speed: 4600rpm
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0512H7D01 SANYO DENKI 109P0512H7D01.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 52x52x15mm; 15.3m3/h; 27dBA; ball bearing
Operating temperature: -20...70°C
Supply voltage: 12V DC
Cable length: 0.3m
Power consumption: 1.2W
Additional functions: lock sensor; reverse polarity protection
Kind of fan: axial
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Current rating: 0.1A
Leads: lead x3
Operating voltage: 7...13.8V
Type of fan: DC
Fan dimensions: 52x52x15mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 15.3m3/h
Noise level: 27dBA
Rotational rate/speed: 4600rpm
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0524A701 109P0524A701 SANYO DENKI 109P0524A701.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 52x52x15mm; 22.5m3/h; 36dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 14...27.6V
Fan dimensions: 52x52x15mm
Power consumption: 2.64W
Current rating: 0.11A
Fan efficiency: 22.5m3/h
Noise level: 36dBA
Kind of Bearing: ball
Rotational rate/speed: 6800rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...60°C
Cable length: 0.3m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
auf Bestellung 49 Stücke:
Lieferzeit 7-14 Tag (e)
6+13.21 EUR
10+ 12.74 EUR
20+ 12.43 EUR
Mindestbestellmenge: 6
109P0524H701 SANYO DENKI 109P0524H701.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 52x52x15mm; 15.3m3/h; 27dBA; ball bearing
Operating temperature: -20...70°C
Impeller material: plastic
Type of fan: DC
Noise level: 27dBA
Additional functions: lock sensor; reverse polarity protection
Operating voltage: 14...27.6V
Kind of fan: axial
Supply voltage: 24V DC
Flammability rating: UL94V-1
Current rating: 50mA
Cable length: 0.3m
Fan efficiency: 15.3m3/h
Rotational rate/speed: 4600rpm
Enclosure material: plastic
Kind of Bearing: ball
Leads: lead x3
Fan dimensions: 52x52x15mm
Min. insulation resistance: 10MΩ
Kind of material: flame retardant
Power consumption: 1.2W
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0524H7D01 SANYO DENKI 109P0524H7D01.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 52x52x15mm; 15.3m3/h; 27dBA; ball bearing
Operating temperature: -20...70°C
Impeller material: plastic
Type of fan: DC
Noise level: 27dBA
Additional functions: lock sensor; reverse polarity protection
Operating voltage: 14...27.6V
Kind of fan: axial
Supply voltage: 24V DC
Flammability rating: UL94V-1
Current rating: 50mA
Cable length: 0.3m
Fan efficiency: 15.3m3/h
Rotational rate/speed: 4600rpm
Enclosure material: plastic
Kind of Bearing: ball
Leads: lead x3
Fan dimensions: 52x52x15mm
Min. insulation resistance: 10MΩ
Kind of material: flame retardant
Power consumption: 1.2W
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0605M702 SANYO DENKI 109P0605M702.pdf Category: DC5V Fans
Description: Fan: DC; axial; 5VDC; 60x60x15mm; 18m3/h; 25dBA; ball; 3100rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 5V DC
Operating voltage: 4.5...5.5V
Fan dimensions: 60x60x15mm
Power consumption: 0.75W
Current rating: 0.15A
Fan efficiency: 18m3/h
Noise level: 25dBA
Kind of Bearing: ball
Rotational rate/speed: 3100rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.3m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0612H602 SANYO DENKI 109P0612H602.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 60x60x20mm; 25.2m3/h; 31dBA; ball; 4200rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 10.2...13.8V
Fan dimensions: 60x60x20mm
Power consumption: 1.56W
Current rating: 0.13A
Fan efficiency: 25.2m3/h
Noise level: 31dBA
Kind of Bearing: ball
Rotational rate/speed: 4200rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.3m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0612M702 SANYO DENKI 109P0612M702.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 60x60x15mm; 18m3/h; 25dBA; ball; 3100rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 10.2...13.8V
Fan dimensions: 60x60x15mm
Power consumption: 0.84W
Current rating: 70mA
Fan efficiency: 18m3/h
Noise level: 25dBA
Kind of Bearing: ball
Rotational rate/speed: 3100rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.3m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0612S701 SANYO DENKI 109P0612S701.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 60x60x15mm; 28.8m3/h; 36dBA; ball; 5000rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 10.2...13.8V
Fan dimensions: 60x60x15mm
Power consumption: 1.8W
Current rating: 0.15A
Fan efficiency: 28.8m3/h
Noise level: 36dBA
Kind of Bearing: ball
Rotational rate/speed: 5000rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.3m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412E601 109P0412E601.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x20mm; 15.6m3/h; 37dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 7...13.8V
Fan dimensions: 40x40x20mm
Power consumption: 1.56W
Current rating: 0.13A
Fan efficiency: 15.6m3/h
Noise level: 37dBA
Kind of Bearing: ball
Rotational rate/speed: 9200rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412F301 San_Ace_E.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 14.64m3/h; 30dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 7...13.8V
Fan dimensions: 40x40x28mm
Power consumption: 1.26W
Current rating: 0.105A
Fan efficiency: 14.64m3/h
Noise level: 30dBA
Kind of Bearing: ball
Rotational rate/speed: 6700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412F3013 109P0412F3013.pdf
109P0412F3013
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 14.64m3/h; 30dBA; ball; 6700rpm
Power consumption: 1.26W
Supply voltage: 12V DC
Current rating: 0.105A
Operating temperature: -20...70°C
Additional functions: lock sensor; reverse polarity protection
Cable length: 0.32m
Rotational rate/speed: 6700rpm
Leads: lead x3
Operating voltage: 7...13.8V
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Type of fan: DC
Fan dimensions: 40x40x28mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 14.64m3/h
Noise level: 30dBA
Kind of fan: axial
Anzahl je Verpackung: 1 Stücke
auf Bestellung 217 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis ohne MwSt
6+13.13 EUR
10+ 12.66 EUR
20+ 12.34 EUR
Mindestbestellmenge: 6
109P0412F302 San_Ace_E.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 14.64m3/h; 30dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 7...13.8V
Fan dimensions: 40x40x28mm
Power consumption: 1.26W
Current rating: 0.105A
Fan efficiency: 14.64m3/h
Noise level: 30dBA
Kind of Bearing: ball
Rotational rate/speed: 6700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412G302 San_Ace_E.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 25.2m3/h; 42dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 7...13.2V
Fan dimensions: 40x40x28mm
Power consumption: 3.72W
Current rating: 0.31A
Fan efficiency: 25.2m3/h
Noise level: 42dBA
Kind of Bearing: ball
Rotational rate/speed: 11500rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...60°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412G3D01 San_Ace_E.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 25.2m3/h; 42dBA; ball bearing
Operating voltage: 7...13.2V
Supply voltage: 12V DC
Additional functions: lock sensor; reverse polarity protection
Enclosure material: plastic
Current rating: 0.31A
Leads: lead x3
Type of fan: DC
Fan dimensions: 40x40x28mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 25.2m3/h
Noise level: 42dBA
Rotational rate/speed: 11500rpm
Power consumption: 3.72W
Cable length: 0.32m
Kind of fan: axial
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Operating temperature: -20...60°C
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412H301 San_Ace_E.pdf
109P0412H301
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 19.2m3/h; 37dBA; ball; 8700rpm
Power consumption: 2.34W
Supply voltage: 12V DC
Current rating: 0.195A
Operating temperature: -20...70°C
Additional functions: lock sensor; reverse polarity protection
Cable length: 0.32m
Rotational rate/speed: 8700rpm
Leads: lead x3
Operating voltage: 7...13.8V
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Type of fan: DC
Fan dimensions: 40x40x28mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 19.2m3/h
Noise level: 37dBA
Kind of fan: axial
Anzahl je Verpackung: 1 Stücke
auf Bestellung 37 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis ohne MwSt
4+18.88 EUR
5+ 14.6 EUR
50+ 13.57 EUR
Mindestbestellmenge: 4
109P0412H3013 109P0412H3013.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 19.2m3/h; 37dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 7...13.8V
Fan dimensions: 40x40x28mm
Power consumption: 2.34W
Current rating: 0.195A
Fan efficiency: 19.2m3/h
Noise level: 37dBA
Kind of Bearing: ball
Rotational rate/speed: 8700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412H302 San_Ace_E.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 19.2m3/h; 37dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 7...13.8V
Fan dimensions: 40x40x28mm
Power consumption: 2.34W
Current rating: 0.195A
Fan efficiency: 19.2m3/h
Noise level: 37dBA
Kind of Bearing: ball
Rotational rate/speed: 8700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412H3023 San_Ace_E.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 19.2m3/h; 37dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 7...13.8V
Fan dimensions: 40x40x28mm
Power consumption: 2.34W
Current rating: 0.195A
Fan efficiency: 19.2m3/h
Noise level: 37dBA
Kind of Bearing: ball
Rotational rate/speed: 8700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412H3D01 San_Ace_E.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 19.2m3/h; 37dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 7...13.8V
Fan dimensions: 40x40x28mm
Power consumption: 2.34W
Current rating: 0.195A
Fan efficiency: 19.2m3/h
Noise level: 37dBA
Kind of Bearing: ball
Rotational rate/speed: 8700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412H601 109P0412H601.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x20mm; 13.5m3/h; 33dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 7...13.8V
Fan dimensions: 40x40x20mm
Power consumption: 1.32W
Current rating: 0.11A
Fan efficiency: 13.5m3/h
Noise level: 33dBA
Kind of Bearing: ball
Rotational rate/speed: 8000rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412H701 109P0412H701.pdf
109P0412H701
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x15mm; 10.8m3/h; 28dBA; ball; 7700rpm
Power consumption: 1.56W
Supply voltage: 12V DC
Current rating: 0.13A
Operating temperature: -20...70°C
Additional functions: lock sensor; reverse polarity protection
Cable length: 0.32m
Rotational rate/speed: 7700rpm
Leads: lead x3
Operating voltage: 10.2...13.8V
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Type of fan: DC
Fan dimensions: 40x40x15mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 10.8m3/h
Noise level: 28dBA
Kind of fan: axial
Anzahl je Verpackung: 1 Stücke
auf Bestellung 148 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis ohne MwSt
7+11.8 EUR
10+ 11.37 EUR
20+ 11.08 EUR
Mindestbestellmenge: 7
109P0412H702 San_Ace_E.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x15mm; 10.8m3/h; 28dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 10.2...13.8V
Fan dimensions: 40x40x15mm
Power consumption: 1.56W
Current rating: 0.13A
Fan efficiency: 10.8m3/h
Noise level: 28dBA
Kind of Bearing: ball
Rotational rate/speed: 7700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412H901 109P0412H901.pdf
109P0412H901
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x10mm; 9m3/h; 25dBA; ball; 6200rpm
Power consumption: 0.84W
Supply voltage: 12V DC
Current rating: 70mA
Operating temperature: -10...60°C
Additional functions: lock sensor; reverse polarity protection
Cable length: 0.32m
Rotational rate/speed: 6200rpm
Leads: lead x3
Operating voltage: 7...13.8V
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Type of fan: DC
Fan dimensions: 40x40x10mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 9m3/h
Noise level: 25dBA
Kind of fan: axial
Anzahl je Verpackung: 1 Stücke
auf Bestellung 84 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis ohne MwSt
6+12.47 EUR
10+ 12.03 EUR
20+ 11.71 EUR
Mindestbestellmenge: 6
109P0412J301 San_Ace_E.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 27.6m3/h; 44dBA; ball; 12500rpm
Operating temperature: -20...60°C
Operating voltage: 7...13.8V
Flammability rating: UL94V-1
Kind of material: flame retardant
Leads: lead x3
Enclosure material: plastic
Type of fan: DC
Fan dimensions: 40x40x28mm
Impeller material: plastic
Min. insulation resistance: 10MΩ
Kind of Bearing: ball
Fan efficiency: 27.6m3/h
Noise level: 44dBA
Rotational rate/speed: 12500rpm
Power consumption: 4.2W
Cable length: 0.32m
Additional functions: lock sensor; reverse polarity protection
Kind of fan: axial
Current rating: 0.35A
Supply voltage: 12V DC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412J3023 San_Ace_E.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 27.6m3/h; 44dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 7...13.8V
Fan dimensions: 40x40x28mm
Power consumption: 4.2W
Current rating: 0.35A
Fan efficiency: 27.6m3/h
Noise level: 44dBA
Kind of Bearing: ball
Rotational rate/speed: 12500rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...60°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412K301 San_Ace_E.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 35.4m3/h; 50dBA; ball bearing
Operating temperature: -20...70°C
Operating voltage: 8...13.2V
Type of fan: DC
Fan dimensions: 40x40x28mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 35.4m3/h
Noise level: 50dBA
Rotational rate/speed: 15500rpm
Power consumption: 6.6W
Cable length: 0.32m
Additional functions: lock sensor; reverse polarity protection
Kind of fan: axial
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Current rating: 0.55A
Supply voltage: 12V DC
Leads: lead x3
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412K3013 109P0412K3013.pdf
109P0412K3013
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 35.4m3/h; 50dBA; ball bearing
Operating temperature: -20...70°C
Operating voltage: 8...13.2V
Type of fan: DC
Fan dimensions: 40x40x28mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 35.4m3/h
Noise level: 50dBA
Rotational rate/speed: 15500rpm
Power consumption: 6.6W
Cable length: 0.32m
Additional functions: lock sensor; reverse polarity protection
Kind of fan: axial
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Current rating: 0.55A
Supply voltage: 12V DC
Leads: lead x3
Anzahl je Verpackung: 1 Stücke
auf Bestellung 269 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis ohne MwSt
6+14.13 EUR
10+ 13.57 EUR
20+ 13.23 EUR
Mindestbestellmenge: 6
109P0412K3023 TR16e_e_en.pdf
109P0412K3023
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 35.4m3/h; 50dBA; ball; 15500rpm
Current rating: 0.55A
Supply voltage: 12V DC
Leads: lead x2
Operating voltage: 8...13.2V
Type of fan: DC
Fan dimensions: 40x40x28mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 35.4m3/h
Noise level: 50dBA
Rotational rate/speed: 15500rpm
Power consumption: 6.6W
Cable length: 0.32m
Additional functions: lock sensor; reverse polarity protection
Kind of fan: axial
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Operating temperature: -20...70°C
Enclosure material: plastic
Anzahl je Verpackung: 1 Stücke
auf Bestellung 304 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis ohne MwSt
6+12.48 EUR
10+ 12.04 EUR
20+ 11.78 EUR
Mindestbestellmenge: 6
109P0412K3D013 San_Ace_E.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 35.4m3/h; 50dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 8...13.2V
Fan dimensions: 40x40x28mm
Power consumption: 6.6W
Current rating: 550mA
Fan efficiency: 35.4m3/h
Noise level: 50dBA
Kind of Bearing: ball
Rotational rate/speed: 15500rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412M302 San_Ace_E.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 9m3/h; 20dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 10.2...13.8V
Fan dimensions: 40x40x28mm
Power consumption: 0.54W
Current rating: 45mA
Fan efficiency: 9m3/h
Noise level: 20dBA
Kind of Bearing: ball
Rotational rate/speed: 4100rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412M602 San_Ace_E.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x20mm; 8.16m3/h; 24dBA; ball; 5000rpm
Supply voltage: 12V DC
Leads: lead x3
Operating voltage: 8...13.8V
Type of fan: DC
Fan dimensions: 40x40x20mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 8.16m3/h
Noise level: 24dBA
Rotational rate/speed: 5000rpm
Power consumption: 0.72W
Cable length: 0.32m
Additional functions: lock sensor; reverse polarity protection
Kind of fan: axial
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Operating temperature: -20...70°C
Enclosure material: plastic
Current rating: 60mA
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412M701 109P0412M701.pdf
109P0412M701
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x15mm; 9m3/h; 24dBA; ball; 6500rpm
Operating temperature: -20...70°C
Type of fan: DC
Fan dimensions: 40x40x15mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 9m3/h
Noise level: 24dBA
Rotational rate/speed: 6500rpm
Power consumption: 1.14W
Cable length: 0.32m
Additional functions: lock sensor; reverse polarity protection
Kind of fan: axial
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Current rating: 95mA
Supply voltage: 12V DC
Leads: lead x3
Operating voltage: 10.2...13.8V
Anzahl je Verpackung: 1 Stücke
auf Bestellung 320 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis ohne MwSt
7+10.94 EUR
10+ 10.54 EUR
20+ 10.28 EUR
Mindestbestellmenge: 7
109P0412M702 San_Ace_E.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x15mm; 9m3/h; 24dBA; ball bearing
Operating temperature: -20...70°C
Leads: lead x3
Supply voltage: 12V DC
Current rating: 95mA
Additional functions: lock sensor; reverse polarity protection
Power consumption: 1.14W
Cable length: 0.32m
Kind of fan: axial
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Operating voltage: 10.2...13.8V
Type of fan: DC
Fan dimensions: 40x40x15mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 9m3/h
Noise level: 24dBA
Rotational rate/speed: 6500rpm
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412P3H013 San_Ace_E.pdf
109P0412P3H013
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 19.2m3/h; 37dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 7...13.8V
Fan dimensions: 40x40x28mm
Power consumption: 2.34W
Current rating: 0.195A
Fan efficiency: 19.2m3/h
Noise level: 37dBA
Kind of Bearing: ball
Rotational rate/speed: 8700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x4
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; PWM; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
auf Bestellung 41 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis ohne MwSt
5+14.67 EUR
10+ 14.13 EUR
20+ 13.73 EUR
Mindestbestellmenge: 5
109P0412S701 109P0412S701.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x15mm; 12m3/h; 32dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 10.2...13.8V
Fan dimensions: 40x40x15mm
Power consumption: 2.16W
Current rating: 0.18A
Fan efficiency: 12m3/h
Noise level: 32dBA
Kind of Bearing: ball
Rotational rate/speed: 8600rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0412S702 San_Ace_E.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x15mm; 12m3/h; 32dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 10.2...13.8V
Fan dimensions: 40x40x15mm
Power consumption: 2.16W
Current rating: 0.18A
Fan efficiency: 12m3/h
Noise level: 32dBA
Kind of Bearing: ball
Rotational rate/speed: 8600rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424B302 San_Ace_E.pdf
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x28mm; 22.8m3/h; 40dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 12...26.4V
Fan dimensions: 40x40x28mm
Power consumption: 3.12W
Current rating: 0.13A
Fan efficiency: 22.8m3/h
Noise level: 40dBA
Kind of Bearing: ball
Rotational rate/speed: 10300rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...60°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424B602 San_Ace_E.pdf
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x20mm; 8.4m3/h; 25dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 20.4...27.6V
Fan dimensions: 40x40x20mm
Power consumption: 1.44W
Current rating: 60mA
Fan efficiency: 8.4m3/h
Noise level: 25dBA
Kind of Bearing: ball
Rotational rate/speed: 5200rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424D601 109P0424D601.pdf
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x20mm; 18.6m3/h; 42dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 12...27.6V
Fan dimensions: 40x40x20mm
Power consumption: 3.12W
Current rating: 0.13A
Fan efficiency: 18.6m3/h
Noise level: 42dBA
Kind of Bearing: ball
Rotational rate/speed: 11000rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...60°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
auf Bestellung 64 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis ohne MwSt
4+19.02 EUR
5+ 15.03 EUR
6+ 14.24 EUR
Mindestbestellmenge: 4
109P0424D6D01 San_Ace_E.pdf
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x20mm; 18.6m3/h; 42dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 12...27.6V
Fan dimensions: 40x40x20mm
Power consumption: 3.12W
Current rating: 0.13A
Fan efficiency: 18.6m3/h
Noise level: 42dBA
Kind of Bearing: ball
Rotational rate/speed: 11000rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...60°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424F302 San_Ace_E.pdf
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x28mm; 14.64m3/h; 30dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 14...27.6V
Fan dimensions: 40x40x28mm
Power consumption: 1.32W
Current rating: 55mA
Fan efficiency: 14.64m3/h
Noise level: 30dBA
Kind of Bearing: ball
Rotational rate/speed: 6700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424F3023 San_Ace_E.pdf
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x28mm; 14.64m3/h; 30dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 14...27.6V
Fan dimensions: 40x40x28mm
Power consumption: 1.32W
Current rating: 55mA
Fan efficiency: 14.64m3/h
Noise level: 30dBA
Kind of Bearing: ball
Rotational rate/speed: 6700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424F602 San_Ace_E.pdf
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x20mm; 10.98m3/h; 28dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 14...27.6V
Fan dimensions: 40x40x20mm
Power consumption: 1.44W
Current rating: 60mA
Fan efficiency: 10.98m3/h
Noise level: 28dBA
Kind of Bearing: ball
Rotational rate/speed: 6500rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424G301 San_Ace_E.pdf
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x28mm; 25.8m3/h; 42dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 12...26.4V
Fan dimensions: 40x40x28mm
Power consumption: 4.56W
Current rating: 0.19A
Fan efficiency: 25.8m3/h
Noise level: 42dBA
Kind of Bearing: ball
Rotational rate/speed: 11500rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...60°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424G3013 109P0424G3013.pdf
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x28mm; 25.8m3/h; 42dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 12...26.4V
Fan dimensions: 40x40x28mm
Power consumption: 4.56W
Current rating: 0.19A
Fan efficiency: 25.8m3/h
Noise level: 42dBA
Kind of Bearing: ball
Rotational rate/speed: 11500rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...60°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424G3023 San_Ace_E.pdf
109P0424G3023
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x28mm; 25.8m3/h; 42dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 12...26.4V
Fan dimensions: 40x40x28mm
Power consumption: 4.56W
Current rating: 0.19A
Fan efficiency: 25.8m3/h
Noise level: 42dBA
Kind of Bearing: ball
Rotational rate/speed: 11500rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...60°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424H301 San_Ace_E.pdf
109P0424H301
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x28mm; 19.2m3/h; 37dBA; ball; 8700rpm
Power consumption: 2.28W
Supply voltage: 24V DC
Current rating: 95mA
Operating temperature: -20...70°C
Additional functions: lock sensor; reverse polarity protection
Cable length: 0.32m
Rotational rate/speed: 8700rpm
Leads: lead x3
Operating voltage: 12...27.6V
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Type of fan: DC
Fan dimensions: 40x40x28mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 19.2m3/h
Noise level: 37dBA
Kind of fan: axial
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424H302 San_Ace_E.pdf
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x28mm; 19.2m3/h; 37dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 12...27.6V
Fan dimensions: 40x40x28mm
Power consumption: 2.28W
Current rating: 95mA
Fan efficiency: 19.2m3/h
Noise level: 37dBA
Kind of Bearing: ball
Rotational rate/speed: 8700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424H3023 San_Ace_E.pdf
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x28mm; 19.2m3/h; 37dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 12...27.6V
Fan dimensions: 40x40x28mm
Power consumption: 2.28W
Current rating: 95mA
Fan efficiency: 19.2m3/h
Noise level: 37dBA
Kind of Bearing: ball
Rotational rate/speed: 8700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424H3D01 San_Ace_E.pdf
109P0424H3D01
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x28mm; 19.2m3/h; 37dBA; ball; 8700rpm
Power consumption: 2.28W
Supply voltage: 24V DC
Current rating: 95mA
Operating temperature: -20...70°C
Additional functions: lock sensor; reverse polarity protection
Cable length: 0.32m
Rotational rate/speed: 8700rpm
Leads: lead x3
Operating voltage: 12...27.6V
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Type of fan: DC
Fan dimensions: 40x40x28mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 19.2m3/h
Noise level: 37dBA
Kind of fan: axial
Anzahl je Verpackung: 1 Stücke
auf Bestellung 240 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis ohne MwSt
6+13.86 EUR
10+ 13.4 EUR
20+ 13.06 EUR
Mindestbestellmenge: 6
109P0424H602 San_Ace_E.pdf
109P0424H602
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x20mm; 19.2m3/h; 37dBA; ball; 8700rpm
Power consumption: 2.28W
Supply voltage: 24V DC
Current rating: 95mA
Operating temperature: -20...70°C
Additional functions: lock sensor; reverse polarity protection
Cable length: 0.32m
Rotational rate/speed: 8700rpm
Leads: lead x2
Operating voltage: 12...27.6V
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Type of fan: DC
Fan dimensions: 40x40x20mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 19.2m3/h
Noise level: 37dBA
Kind of fan: axial
Anzahl je Verpackung: 1 Stücke
auf Bestellung 19 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis ohne MwSt
5+14.83 EUR
6+ 14.04 EUR
10+ 13.86 EUR
50+ 13.18 EUR
Mindestbestellmenge: 5
109P0424H6D01 San_Ace_E.pdf
109P0424H6D01
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x20mm; 13.98m3/h; 35dBA; ball; 8300rpm
Power consumption: 1.68W
Supply voltage: 24V DC
Current rating: 70mA
Operating temperature: -10...70°C
Cable length: 0.3m
Rotational rate/speed: 8300rpm
Leads: lead x3
Operating voltage: 12...27.6V
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Type of fan: DC
Fan dimensions: 40x40x20mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Kind of Bearing: ball
Fan efficiency: 13.98m3/h
Static pressure: 7.11mm H2O
Noise level: 35dBA
Wire size: 24AWG
Kind of fan: axial
Anzahl je Verpackung: 1 Stücke
auf Bestellung 254 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis ohne MwSt
5+14.53 EUR
10+ 13.91 EUR
20+ 13.6 EUR
50+ 13.57 EUR
Mindestbestellmenge: 5
109P0424H7D01 San_Ace_E.pdf
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 52x52x15mm; 13.38m3/h; 35dBA; ball bearing
Cable length: 0.32m
Fan efficiency: 13.38m3/h
Operating temperature: -20...70°C
Rotational rate/speed: 8300rpm
Enclosure material: plastic
Kind of Bearing: ball
Leads: lead x3
Fan dimensions: 52x52x15mm
Min. insulation resistance: 10MΩ
Kind of material: flame retardant
Power consumption: 1.68W
Impeller material: plastic
Type of fan: DC
Noise level: 35dBA
Additional functions: lock sensor; reverse polarity protection
Operating voltage: 12...27.6V
Kind of fan: axial
Supply voltage: 24V DC
Flammability rating: UL94V-1
Current rating: 70mA
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424J3023 San_Ace_E.pdf
109P0424J3023
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x28mm; 27.6m3/h; 44dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 12...26.4V
Fan dimensions: 40x40x28mm
Power consumption: 4.32W
Current rating: 0.18A
Fan efficiency: 27.6m3/h
Noise level: 44dBA
Kind of Bearing: ball
Rotational rate/speed: 12500rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x2
Operating temperature: -20...60°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0424J3D013 page=40P28
Hersteller: SANYO DENKI
109P0424J3D013 DC24V Fans
Produkt ist nicht verfügbar
109P0424R3013 109P0424R3013.pdf
109P0424R3013
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x28mm; 30.6m3/h; 47dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 12...26.4V
Fan dimensions: 40x40x28mm
Power consumption: 6W
Current rating: 0.25A
Fan efficiency: 30.6m3/h
Noise level: 47dBA
Kind of Bearing: ball
Rotational rate/speed: 14000rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...60°C
Cable length: 0.32m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0505M701 109P0505M701.pdf
Hersteller: SANYO DENKI
Category: DC5V Fans
Description: Fan: DC; axial; 5VDC; 52x52x15mm; 12.3m3/h; 22dBA; ball bearing
Leads: lead x3
Operating voltage: 4.5...5.5V
Type of fan: DC
Fan dimensions: 52x52x15mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 12.3m3/h
Noise level: 22dBA
Rotational rate/speed: 3700rpm
Power consumption: 0.75W
Cable length: 0.3m
Additional functions: lock sensor; reverse polarity protection
Kind of fan: axial
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Operating temperature: -20...70°C
Enclosure material: plastic
Current rating: 0.15A
Supply voltage: 5V DC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0512A701 109P0512A701.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 52x52x15mm; 22.5m3/h; 36dBA; ball bearing
Enclosure material: plastic
Current rating: 0.21A
Operating temperature: -20...70°C
Supply voltage: 12V DC
Leads: lead x3
Operating voltage: 10.2...13.8V
Type of fan: DC
Fan dimensions: 52x52x15mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 22.5m3/h
Noise level: 36dBA
Rotational rate/speed: 6800rpm
Power consumption: 2.52W
Cable length: 0.3m
Additional functions: lock sensor; reverse polarity protection
Kind of fan: axial
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0512A702 109P0512A702.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 52x52x15mm; 22.5m3/h; 36dBA; ball; 6800rpm
Supply voltage: 12V DC
Operating temperature: -20...70°C
Leads: lead x3
Cable length: 0.3m
Operating voltage: 10.2...13.8V
Additional functions: lock sensor; reverse polarity protection
Enclosure material: plastic
Current rating: 0.21A
Kind of material: flame retardant
Type of fan: DC
Min. insulation resistance: 10MΩ
Kind of fan: axial
Fan efficiency: 22.5m3/h
Noise level: 36dBA
Rotational rate/speed: 6800rpm
Kind of Bearing: ball
Power consumption: 2.52W
Flammability rating: UL94V-1
Impeller material: plastic
Fan dimensions: 52x52x15mm
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0512H702 109P0512H702.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 52x52x15mm; 15.3m3/h; 27dBA; ball bearing
Operating temperature: -20...70°C
Supply voltage: 12V DC
Cable length: 0.3m
Power consumption: 1.2W
Additional functions: lock sensor; reverse polarity protection
Kind of fan: axial
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Current rating: 0.1A
Leads: lead x3
Operating voltage: 7...13.8V
Type of fan: DC
Fan dimensions: 52x52x15mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 15.3m3/h
Noise level: 27dBA
Rotational rate/speed: 4600rpm
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0512H7D01 109P0512H7D01.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 52x52x15mm; 15.3m3/h; 27dBA; ball bearing
Operating temperature: -20...70°C
Supply voltage: 12V DC
Cable length: 0.3m
Power consumption: 1.2W
Additional functions: lock sensor; reverse polarity protection
Kind of fan: axial
Kind of material: flame retardant
Min. insulation resistance: 10MΩ
Enclosure material: plastic
Current rating: 0.1A
Leads: lead x3
Operating voltage: 7...13.8V
Type of fan: DC
Fan dimensions: 52x52x15mm
Impeller material: plastic
Flammability rating: UL94V-1
Kind of Bearing: ball
Fan efficiency: 15.3m3/h
Noise level: 27dBA
Rotational rate/speed: 4600rpm
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0524A701 109P0524A701.pdf
109P0524A701
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 52x52x15mm; 22.5m3/h; 36dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 14...27.6V
Fan dimensions: 52x52x15mm
Power consumption: 2.64W
Current rating: 0.11A
Fan efficiency: 22.5m3/h
Noise level: 36dBA
Kind of Bearing: ball
Rotational rate/speed: 6800rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...60°C
Cable length: 0.3m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
auf Bestellung 49 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis ohne MwSt
6+13.21 EUR
10+ 12.74 EUR
20+ 12.43 EUR
Mindestbestellmenge: 6
109P0524H701 109P0524H701.pdf
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 52x52x15mm; 15.3m3/h; 27dBA; ball bearing
Operating temperature: -20...70°C
Impeller material: plastic
Type of fan: DC
Noise level: 27dBA
Additional functions: lock sensor; reverse polarity protection
Operating voltage: 14...27.6V
Kind of fan: axial
Supply voltage: 24V DC
Flammability rating: UL94V-1
Current rating: 50mA
Cable length: 0.3m
Fan efficiency: 15.3m3/h
Rotational rate/speed: 4600rpm
Enclosure material: plastic
Kind of Bearing: ball
Leads: lead x3
Fan dimensions: 52x52x15mm
Min. insulation resistance: 10MΩ
Kind of material: flame retardant
Power consumption: 1.2W
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0524H7D01 109P0524H7D01.pdf
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 52x52x15mm; 15.3m3/h; 27dBA; ball bearing
Operating temperature: -20...70°C
Impeller material: plastic
Type of fan: DC
Noise level: 27dBA
Additional functions: lock sensor; reverse polarity protection
Operating voltage: 14...27.6V
Kind of fan: axial
Supply voltage: 24V DC
Flammability rating: UL94V-1
Current rating: 50mA
Cable length: 0.3m
Fan efficiency: 15.3m3/h
Rotational rate/speed: 4600rpm
Enclosure material: plastic
Kind of Bearing: ball
Leads: lead x3
Fan dimensions: 52x52x15mm
Min. insulation resistance: 10MΩ
Kind of material: flame retardant
Power consumption: 1.2W
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0605M702 109P0605M702.pdf
Hersteller: SANYO DENKI
Category: DC5V Fans
Description: Fan: DC; axial; 5VDC; 60x60x15mm; 18m3/h; 25dBA; ball; 3100rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 5V DC
Operating voltage: 4.5...5.5V
Fan dimensions: 60x60x15mm
Power consumption: 0.75W
Current rating: 0.15A
Fan efficiency: 18m3/h
Noise level: 25dBA
Kind of Bearing: ball
Rotational rate/speed: 3100rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.3m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0612H602 109P0612H602.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 60x60x20mm; 25.2m3/h; 31dBA; ball; 4200rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 10.2...13.8V
Fan dimensions: 60x60x20mm
Power consumption: 1.56W
Current rating: 0.13A
Fan efficiency: 25.2m3/h
Noise level: 31dBA
Kind of Bearing: ball
Rotational rate/speed: 4200rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.3m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0612M702 109P0612M702.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 60x60x15mm; 18m3/h; 25dBA; ball; 3100rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 10.2...13.8V
Fan dimensions: 60x60x15mm
Power consumption: 0.84W
Current rating: 70mA
Fan efficiency: 18m3/h
Noise level: 25dBA
Kind of Bearing: ball
Rotational rate/speed: 3100rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.3m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
109P0612S701 109P0612S701.pdf
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 60x60x15mm; 28.8m3/h; 36dBA; ball; 5000rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 10.2...13.8V
Fan dimensions: 60x60x15mm
Power consumption: 1.8W
Current rating: 0.15A
Fan efficiency: 28.8m3/h
Noise level: 36dBA
Kind of Bearing: ball
Rotational rate/speed: 5000rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: lead x3
Operating temperature: -20...70°C
Cable length: 0.3m
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Wählen Sie Seite:   [  << Vorherige Seite ]  1 13 26 39 52 65 72 73 74 75 76 77 78 79 80 81 82 91 104 117 130 136  [ Nächste Seite >> ]
