BK4014B B&K PRECISION
Hersteller: B&K PRECISION
Category: Generators and Frequency Meters
Description: Generator: function; 12MHz; LCD; Ch: 1; Interface: USB; 0÷50°C; 0.01%
Type of generator: function
Maximum waveform frequency: 12MHz
Waveform frequency range: 0,01Hz...1MHz (triangle waveform); 0,01Hz...12MHz (rectangular waveform); 0,01Hz...12MHz (sinus waveform)
Kind of display used: LCD
Number of channels: 1
Output parameters: amplitude at 50Ω load >10Vpp; amplitude flatness: ±0,5dB to 1MHz; ±1dB to 12MHz; amplitude without load: 20Vpp; impedance: 50Ω
Sweep mode: mode: linear or logarithmic; up or down; period: 10m...100s
Dimensions: 213x88x210mm
Interface: USB
Kind of modulation: AM; FM
Waveforms: ramp; sinus; square; triangle
Protection: anti-overvoltage OVP; short circuit protection SCP
Operating temperature: 0...50°C
Accuracy: 0.01%
Standard equipment: manufacturer's calibration certificate; power supply; USB cable
Measuring instrument features: 10 sets memory; Direct Digital Synthesized (DDS) technology
Software: download from manufacturers website
Supply voltage: 100...240V AC
Anzahl je Verpackung: 1 Stücke
Category: Generators and Frequency Meters
Description: Generator: function; 12MHz; LCD; Ch: 1; Interface: USB; 0÷50°C; 0.01%
Type of generator: function
Maximum waveform frequency: 12MHz
Waveform frequency range: 0,01Hz...1MHz (triangle waveform); 0,01Hz...12MHz (rectangular waveform); 0,01Hz...12MHz (sinus waveform)
Kind of display used: LCD
Number of channels: 1
Output parameters: amplitude at 50Ω load >10Vpp; amplitude flatness: ±0,5dB to 1MHz; ±1dB to 12MHz; amplitude without load: 20Vpp; impedance: 50Ω
Sweep mode: mode: linear or logarithmic; up or down; period: 10m...100s
Dimensions: 213x88x210mm
Interface: USB
Kind of modulation: AM; FM
Waveforms: ramp; sinus; square; triangle
Protection: anti-overvoltage OVP; short circuit protection SCP
Operating temperature: 0...50°C
Accuracy: 0.01%
Standard equipment: manufacturer's calibration certificate; power supply; USB cable
Measuring instrument features: 10 sets memory; Direct Digital Synthesized (DDS) technology
Software: download from manufacturers website
Supply voltage: 100...240V AC
Anzahl je Verpackung: 1 Stücke
