Hersteller: PEAKTECH
Category: Probes & accessories of temperatures
Description: Probe: K-type temperature; -50÷700°C; Probe l: 162mm; ±2%
Type of measuring probe: K-type temperature
Temperature measuring range: -50...700°C
Probe length: 162mm
Temperature measurement accuracy: ±2%
Kind of temperature probe: immersion; penetration; surface
Cable length: 1.75m

Hersteller: PEAKTECH
Category: Probes & accessories of temperatures
Description: Probe: K-type temperature; -50÷250°C; Probe l: 1.5mm; Len: 2m
Type of measuring probe: K-type temperature
Temperature measuring range: -50...250°C
Probe length: 1.5mm
Temperature measurement accuracy: ±0.5°C
Kind of temperature probe: penetration; surface
Cable length: 2m

Hersteller: PEAKTECH
Category: Probes & accessories of temperatures
Description: Probe: K-type temperature; -50÷300°C; Probe l: 3mm; Accur: ±2.5°C
Type of measuring probe: K-type temperature
Temperature measuring range: -50...300°C
Probe length: 3mm
Temperature measurement accuracy: ±2.5°C
Kind of temperature probe: immersion; penetration; surface
Cable length: 0.7m

Hersteller: PEAKTECH
Category: Probes & accessories of temperatures
Description: Probe: K-type temperature; -40÷204°C; Accur: ±2.5°C
Type of measuring probe: K-type temperature
Temperature measuring range: -40...204°C
Temperature measurement accuracy: ±2.5°C
Kind of temperature probe: immersion; penetration; surface
Cable/adapter structure: banana 4mm plug x2

Hersteller: PEAKTECH
Category: Probes & accessories of temperatures
Description: Probe: K-type temperature; -50÷1000°C; Probe l: 135mm; Len: 1.2m
Type of measuring probe: K-type temperature
Temperature measuring range: -50...1000°C
Probe length: 135mm
Temperature measurement accuracy: ±2.5°C
Kind of temperature probe: immersion; penetration; surface
Cable length: 1.2m

Hersteller: PEAKTECH
Category: Probes for Oscilloscopes and Scopometers
Description: Probe: for oscilloscope; passive,high-impedance; 1: 1,10: 1; 300V
Cable/adapter structure: BNC plug
Input impedance: 1MΩ/56pF (1:1); 10MΩ/13pF (10:1)
Standard equipment: adjusting tool; cable; channel identifier; grapple hook; insulating tip; test probe
Max. input voltage: 300V
Attenuator: 1:1; 10:1
Kind of probe: high-impedance; passive
Type of measuring probe: for oscilloscope
Band: 6MHz (1:1); 100MHz (10:1)
Rise time: 3.5ns (10:1); 58ns (1:1)
Conform to the norm: CAT I 600V; CAT II 300V; EN 61010
Cable length: 1.2m

Hersteller: PEAKTECH
Category: Probes for Oscilloscopes and Scopometers
Description: Probe: for oscilloscope; passive,high-impedance; 1: 1,10: 1; 300V
Conform to the norm: CAT I 600V; CAT II 300V; EN 61010
Cable length: 1.2m
Cable/adapter structure: BNC plug
Input impedance: 1MΩ/56pF (1:1); 10MΩ/13pF (10:1)
Standard equipment: adjusting tool; BNC adapter; cable; channel identifier; grapple hook; insulating tip; test probe
Max. input voltage: 300V
Attenuator: 1:1; 10:1
Kind of probe: high-impedance; passive
Type of measuring probe: for oscilloscope
Band: 6MHz (1:1); 250MHz (10:1)
Rise time: 1.4ns (10:1); 58ns (1:1)

Hersteller: PEAKTECH
Category: Probes for Oscilloscopes and Scopometers
Description: Probe: for oscilloscope; passive,high-impedance; 250MHz(100: 1)
Type of measuring probe: for oscilloscope
Kind of probe: high-impedance; passive
Cable length: 1.2m
Standard equipment: adjusting tool; BNC adapter; cable; channel identifier; grapple hook; insulating tip; test probe
Input impedance: 100MΩ/5.5pF
Cable/adapter structure: BNC plug
Attenuator: 100:1
Band: 250MHz (100:1)
Rise time: ≤1.4ns
Max. input voltage: 1.5kV

Hersteller: PEAKTECH
Category: Probes for Oscilloscopes and Scopometers
Description: Probe: for oscilloscope; passive,high-impedance; 1: 1,10: 1; 300V
Band: 6MHz (1:1); 60MHz (10:1)
Conform to the norm: CAT I 600V; CAT II 300V; EN 61010
Cable length: 1.2m
Cable/adapter structure: BNC plug
Input impedance: 1MΩ/91pF (1:1); 10MΩ/18pF (10:1)
Standard equipment: adjusting tool; cable; channel identifier; grapple hook; insulating tip
Max. input voltage: 300V
Attenuator: 1:1; 10:1
Kind of probe: high-impedance; passive
Type of measuring probe: for oscilloscope
Rise time: ≤5.8ns (10:1); 58ns (1:1)

Hersteller: PEAKTECH
Category: Electromagnet. and Magnetic Field Meters
Description: Tester: non-contact magnetic field detector; 63H,98H,401H,810H
Type of tester: non-contact magnetic field detector
Power supply: battery LR03 AAA 1,5V x2
Measuring instrument features: clip; optical (LED)indication of detected magnetic field; white LED torch
Standard equipment: user's manual
Dimensions: 157x26mm
Battery/ rechargeable battery: battery LR03 AAA 1,5V x2
Range of detectable magnetic field: 63H; 98H; 401H; 810H
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Portable digital multimeters
Description: Digital multimeter; LCD; 3,5 digit (2000); VAC: 2V,20V,200V,600V
Kind of display used: LCD
Power supply: battery LR03 AAA 1,5V x2
Conform to the norm: CAT IV 600V; EN 61010
Standard equipment: user's manual
Measuring instrument features: automatic power-off; built-in measuring cables; built-in torch; contactless voltage detector; low battery indicator; manual HOLD function or automatic PRE-HOLD; overflow indication; polarization indicator
Type of meter: digital multimeter
Continuity test: acoustic indication; <150Ω
Measurement: AC current; AC voltage; continuity; DC current; DC voltage; resistance
Dimensions (W x H x D): 55x110x40mm
AC current measuring range: 0.2mA; 2mA; 20mA; 200mA
Resistance measuring range: 200Ω; 2kΩ; 20kΩ; 200kΩ; 2MΩ; 20MΩ
DC current measuring range: 0.2mA; 2mA; 20mA; 200mA
DC voltage measuring range: 200mV; 2V; 20V; 200V; 600V
AC voltage measuring range: 2V; 20V; 200V; 600V
Diode test: 1mA @1.5V
Battery/ rechargeable battery: battery LR03 AAA 1,5V x2
Display parameters: 3,5 digit (2000)
AC current measuring accuracy: ±(2.5% + 10 digit)
DC voltage measuring accuracy: ±(0.5% + 3 digit)
DC current measuring accuracy: ±(2% + 8 digit)
AC voltage measuring accuracy: ±(1% + 8 digit)
Resistance measuring accuracy: ±(0.8%+5 digit)
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Indicators, Voltage & Continuity Testers
Description: Tester: non-contact voltage detector; 50÷1000VAC; 50/60Hz
Type of tester: non-contact voltage detector
Detected voltage range: 50...1000V AC
Frequency range of detectable voltage: 50/60Hz
Pollution degree: 2
Additional functions: white LED torch
Operating temperature: -10...50°C
Conform to the norm: CAT III 1000V; EN 61010
Power supply: battery AAA 1,5V x2
Measuring instrument features: clip; optical (LED) and acoustic indication of detected voltage
Dimensions: 157x26mm
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Indicators, Voltage & Continuity Testers
Description: Tester: non-contact voltage detector; 50÷1000VAC; 50/60Hz
Type of tester: non-contact voltage detector
Detected voltage range: 50...1000V AC
Frequency range of detectable voltage: 50/60Hz
Pollution degree: 2
Additional functions: white LED torch
Operating temperature: 0...50°C
Conform to the norm: CAT IV 1000V; EN 61010
Power supply: battery AAA 1,5V x2
Measuring instrument features: optical (LED) indication of detected voltage; vibration mode
Dimensions: 155x25x17mm
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Indicators, Voltage & Continuity Testers
Description: Tester: non-contact voltage detector; 12÷1000VAC; 50/60Hz
Type of tester: non-contact voltage detector
Detected voltage range: 0.012...1kV AC
Frequency range of detectable voltage: 50/60Hz
Pollution degree: 2
Additional functions: white LED torch
Operating temperature: 0...50°C
Conform to the norm: CAT IV 1000V; EN 61010
Power supply: battery AAA 1,5V x2
Measuring instrument features: optical (LED) indication of detected voltage; vibration mode
Dimensions: 160x28x24mm
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Portable digital multimeters
Description: Digital multimeter; LCD; 3,5 digit (2000); VAC: 200V,600V
Kind of display used: LCD
Power supply: battery 6LR61 9V x1
Conform to the norm: CAT IV 600V; EN 61010
Illumination: yes
Standard equipment: case; test leads; user's manual
Measuring instrument features: low battery indicator; socket for testing transistors' gain (hFE) parameter
Type of meter: digital multimeter
Test: battery
Measurement: AC voltage; DC current; DC voltage; resistance
Dimensions (W x H x D): 70x150x48mm
Resistance measuring range: 200Ω; 2kΩ; 20kΩ; 200kΩ; 2MΩ
DC current measuring range: 2mA; 20mA; 200mA; 10A
DC voltage measuring range: 200mV; 2V; 20V; 200V; 600V
AC voltage measuring range: 200V; 600V
Diode test: 1mA @2.8V
Battery/ rechargeable battery: battery 6LR61 9V x1
Display parameters: 3,5 digit (2000)
DC voltage measuring accuracy: ±(0.5% + 2 digit)
DC current measuring accuracy: ±(1% + 2 digit)
AC voltage measuring accuracy: ±(1.2% + 10 digit)
Resistance measuring accuracy: ±(0.8%+2 digit)
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Portable digital multimeters
Description: Digital multimeter; LCD; 3,5 digit (2000); VAC: 200V,600V
Type of meter: digital multimeter
Kind of display used: LCD
Display parameters: 3,5 digit (2000)
Power supply: battery LR03 AAA 1,5V x2
Measuring instrument features: automatic power-off; HOLD function; impact resistant holster; low battery indicator; manual ranging; MIN/MAX function
Standard equipment: case; test leads; user's manual
Measurement: AC current; AC voltage; continuity; DC current; DC voltage; resistance
Conform to the norm: CAT III 600V; CAT IV 300V; EN 61010
Battery/ rechargeable battery: battery LR03 AAA 1,5V x2
Test: battery
Continuity test: acoustic indication; <50Ω
True effective value measurement: True RMS AC
AC current measuring range: 200mA; 10A
Resistance measuring range: 200Ω; 2kΩ; 20kΩ; 200kΩ; 2MΩ
DC current measuring range: 200mA; 10A
DC voltage measuring range: 200mV; 2V; 20V; 200V; 600V
AC voltage measuring range: 200V; 600V
Diode test: 1mA @2V
AC current measuring accuracy: ±(1.2% + 5 digit)
DC voltage measuring accuracy: ±(0.5% + 5 digit)
DC current measuring accuracy: ±(1.2% + 5 digit)
AC voltage measuring accuracy: ±(1.2% + 10 digit)
Resistance measuring accuracy: ±(0.8%+5 digit)
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Portable digital multimeters
Description: Digital multimeter; LCD; 3,75 digit (4000); True RMS AC
Type of meter: digital multimeter
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance
Kind of display used: LCD
Display parameters: 3,75 digit (4000)
DC voltage measuring range: 400mV; 4V; 40V; 400V; 600V
DC voltage measuring accuracy: ±(0.5% + 5 digit)
AC voltage measuring range: 4V; 40V; 400V; 600V
AC voltage measuring accuracy: ±(1.2% + 3 digit)
DC current measuring range: 0.4mA; 4mA; 40mA; 400mA; 4A; 10A
DC current measuring accuracy: ±(1% + 5 digit)
AC current measuring range: 40µA; 0.4mA; 4mA; 40mA; 400mA; 4A; 10A
AC current measuring accuracy: ±(1% + 5 digit)
True effective value measurement: True RMS AC
Resistance measuring range: 0.4kΩ; 4kΩ; 40kΩ; 400kΩ; 4MΩ; 40MΩ
Capacitance measuring range: 99.99nF; 999.9nF; 9.999µF; 99.99µF; 999.9µF; 9.999mF; 99.99mF
Capacitance measuring accuracy: ±(3%+ 5 digit)
Frequency measuring range: 9.999Hz; 99.99Hz; 999.9Hz; 9.999kHz; 99.99kHz; 999.9kHz; 9.999MHz
Frequency measuring accuracy: ±(1.2%+5 digit)
Temperature measuring range: -18...1000°C
Temperature measurement accuracy: ±(1.5% + 5°C)
Resistance measuring accuracy: ±(1.2%+5 digit)
Diode test: 1mA @3V
Test: battery
Continuity test: acoustic indication; <50Ω
Power supply: battery LR03 AAA 1,5V x2
Standard equipment: case; test leads; user's manual
Conform to the norm: CAT III 600V; CAT IV 300V; EN 61010
Measuring instrument features: automatic power-off; autoranging; contactless voltage detector; HOLD function; impact resistant holster; low battery indicator; MIN/MAX function
Battery/ rechargeable battery: battery LR03 AAA 1,5V x2
Illumination: yes
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Portable digital multimeters
Description: Digital multimeter; LCD; 3,5 digit (2000); VAC: 200V,300V
Type of meter: digital multimeter
Measurement: AC voltage; continuity; DC current; DC voltage; resistance; temperature (external probe required)
Kind of display used: LCD
Display parameters: 3,5 digit (2000)
DC voltage measuring range: 200mV; 2V; 20V; 200V; 300V
DC voltage measuring accuracy: ±(0.5% + 5 digit)
AC voltage measuring range: 200V; 300V
AC voltage measuring accuracy: ±(1.2% + 5 digit)
DC current measuring range: 0.2mA; 2mA; 20mA; 200mA; 10A
DC current measuring accuracy: ±(1% + 5 digit)
Resistance measuring range: 200Ω; 2kΩ; 20kΩ; 200kΩ; 2MΩ
Resistance measuring accuracy: ±(1.2%+5 digit)
Diode test: 1.5mA @2800mV
Continuity test: acoustic indication; 20Ω...150Ω
Power supply: battery 6LR61 9V x1
Standard equipment: K-type thermocouple; test leads; user's manual
Conform to the norm: CAT III 300V; EN 61010
Related items: 5790D; 5793D; 5794D; 5795D; 5797D; BKP60; EX871515; EX881602; EX881603; EX881605; PKT-PTA; PKT-PTF-10; PKT-PTF-20; PKT-PTF-25; PKT-PTF-30; PKT-PTF-40; PKT-PTF-50; PKT-PTF-55; PKT-PTF-56; PKT-PTF-60; SE027; SE028; SE029; SE030; SE031; SE059; SE060; SE061; SE062; SE001; SE002; SE003; SE004; SE000; TESTO-06020393; TESTO-06020645; TESTO-06024592; TESTO-06024892; TESTO-06280020; TESTO-06281292; TESTO-06287533; TP200; TP400; TP870; TP873; TP873-5M; TP882; TP-111; TP-112; TP-02; TP-03; TP-04; TP-06; TP-08; TP-09; TPK-59; TPK-62; UTT10K; UTT12
Dimensions (W x H x D): 70x140x30mm
Measuring instrument features: low battery indicator
Battery/ rechargeable battery: battery 6LR61 9V x1
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Portable digital multimeters
Description: Digital multimeter; LCD; 3,5 digit (2000); VAC: 200V,600V
Kind of display used: LCD
Power supply: battery 6LR61 9V x1
Conform to the norm: CAT III 600V; EN 61010
Illumination: yes
Standard equipment: case; test leads; user's manual
Measuring instrument features: contactless voltage detector; HOLD function; low battery indicator; polarization indicator
Type of meter: digital multimeter
Test: battery
Continuity test: acoustic indication; <30Ω
Measurement: AC voltage; continuity; DC current; DC voltage; resistance
Dimensions (W x H x D): 65x140x40mm
Resistance measuring range: 200Ω; 2kΩ; 20kΩ; 200kΩ; 2MΩ
DC current measuring range: 2mA; 20mA; 200mA; 10A
DC voltage measuring range: 200mV; 2V; 20V; 200V; 600V
AC voltage measuring range: 200V; 600V
Diode test: 1mA @2.8V
Battery/ rechargeable battery: battery 6LR61 9V x1
Display parameters: 3,5 digit (2000)
DC voltage measuring accuracy: ±(0.5% + 2 digit)
DC current measuring accuracy: ±(1% + 2 digit)
AC voltage measuring accuracy: ±(1.2% + 10 digit)
Resistance measuring accuracy: ±(0.8%+2 digit)
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Portable digital multimeters
Description: Digital multimeter; LCD; 3,5 digit (1999); I DC: 20mA,200mA
Type of meter: digital multimeter
Measurement: AC current; AC voltage; continuity; DC current; DC voltage; resistance
Kind of display used: LCD
Display parameters: 3,5 digit (1999)
DC voltage measuring range: 200mV; 2V; 20V; 200V; 600V
DC voltage measuring accuracy: ±(0.7% + 2 digit)
AC voltage measuring range: 200mV; 2V; 20V; 200V; 600V
AC voltage measuring accuracy: ±(0.8% + 3 digit)
DC current measuring range: 20mA; 200mA
DC current measuring accuracy: ±(1.5% + 3 digit)
AC current measuring range: 20mA; 200mA
AC current measuring accuracy: ±(2% + 3 digit)
Resistance measuring range: 200Ω; 2kΩ; 20kΩ; 200kΩ; 2MΩ; 20MΩ
Resistance measuring accuracy: ±(1%+1 digit)
Diode test: 1mA @1.5V
Continuity test: acoustic indication; <50Ω
Power supply: battery LR03 AAA 1,5V x2
Standard equipment: test leads
Conform to the norm: CAT III 600V; EN 61010
Dimensions (W x H x D): 43x222x28mm
Measuring instrument features: auto and manual ranging; automatic power-off; built-in measuring tip; contactless voltage detector; HOLD function; logic test; low battery indicator; MAX function; overflow indicator; polarization indicator
Battery/ rechargeable battery: battery LR03 AAA 1,5V x2
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Indicators, Voltage & Continuity Testers
Description: Tester: electrical; LCD; 3,5 digit (1999); Sampling: 2-3x/s; IP64
IP rating: IP64
Body dimensions: 52x255x40mm
Conform to the norm: CAT III 690V; CAT IV 600V; EN 61010
Additional functions: torch
Type of tester: electrical
Illumination: yes
Standard equipment: case; user's manual
Power supply: battery LR03 AAA 1,5V x2
Kind of display used: LCD
Measuring instrument features: AC/DC voltage indicator; AutoTest function; indicates phase sequence; low impedance test; polarization indicator
Weight without batteries: 215g
Continuity test: acoustic indication; <200kΩ
Sampling: 2-3x/s
Bargraph: yes
Measurement: AC voltage; DC voltage
Bandwidth for AC voltage measurements: 50/60Hz
DC voltage measuring range: 6V; 12V; 24V; 50V; 120V; 230V; 400V; 690V
AC voltage measuring range: 6V; 12V; 24V; 50V; 120V; 230V; 400V
Battery/ rechargeable battery: battery LR03 AAA 1,5V x2
Display parameters: 3,5 digit (1999)
DC voltage measuring accuracy: ±(1% + 3 digit)
AC voltage measuring accuracy: ±(1.5% + 5 digit)
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Indicators, Voltage & Continuity Testers
Description: Tester: electrical; LED; 0÷60Hz; Additional functions: torch; IP64
IP rating: IP64
Body dimensions: 52x255x40mm
Conform to the norm: CAT III 690V; CAT IV 600V; EN 61010
Additional functions: torch
Type of tester: electrical
Standard equipment: case; user's manual
Power supply: battery LR03 AAA 1,5V x2
Kind of display used: LED
Measuring instrument features: AC/DC voltage indicator; AutoTest function; indicates phase sequence; polarization indicator
Weight without batteries: 215g
Continuity test: acoustic indication; <300kΩ
Measurement: AC voltage; DC voltage
Bandwidth for AC voltage measurements: 0...60Hz
DC voltage measuring range: 12V; 24V; 36V; 50V; 120V; 230V; 400V; 690V
AC voltage measuring range: 12V; 24V; 36V; 50V; 120V; 230V; 400V; 690V
Battery/ rechargeable battery: battery LR03 AAA 1,5V x2
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Indicators, Voltage & Continuity Testers
Description: Tester: electrical; LCD; 3,5 digit (1999); VAC: 6÷1000V; 0÷400Hz
Measurement: AC voltage; DC voltage
Kind of display used: LCD
Display parameters: 3,5 digit (1999)
Bargraph: yes
DC voltage measuring range: 6...1000V
DC voltage measuring accuracy: ±(3% + 5 digit)
AC voltage measuring range: 6...1000V
AC voltage measuring accuracy: ±(3% + 5 digit)
Bandwidth for AC voltage measurements: 0...400Hz
Continuity test: acoustic indication; <400kΩ
Type of tester: electrical
IP rating: IP64
Body dimensions: 70x255x30mm
Weight without batteries: 270g
Power supply: battery LR03 AAA 1,5V x2
Standard equipment: case; user's manual
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Additional functions: torch
Measuring instrument features: AC/DC voltage indicator; indicates phase sequence; low impedance test; polarization indicator
Battery/ rechargeable battery: battery LR03 AAA 1,5V x2
Illumination: yes
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Miliohmmeters
Description: Milli-ohm meter; LCD; 3,5 digit; ±(0.5%+2digit)
Protection: anti-overvoltage OVP; overheating OTP
Dimensions: 250x110x190mm
Standard equipment: test leads; user's manual
Measuring instrument features: automatic power-off; HOLD function
Type of meter: milli-ohm meter
Resistance measuring range: 0...200mΩ; 2Ω; 20Ω; 200Ω; 2kΩ
Test current: 1mA @ 0Ω...2kΩ; 10mA @ 0Ω...20Ω; 10mA @ 0Ω...200Ω; 100mA @ 0Ω...200mΩ; 100mA @ 0Ω...2Ω
Battery/ rechargeable battery: battery LR6 AA 1,5V x8
Display parameters: 3,5 digit
Resistance measuring accuracy: ±(0.5%+2 digit)
Kind of display used: LCD
Power supply: battery LR6 AA 1,5V x8
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 500Msps; 2Mpts/ch; LCD TFT 8"
Interface: USB
Max. input voltage: 400V
Number of channels: 2
Standard equipment: BNC cable x2; case; logic probe; mains cable; oscilloscope probe x2; USB cable; user's manual
Trigger: alternate; falling-edge; pulse; rising-edge; slope; video signal
Memory record length: 2Mpts/ch
Band: 100MHz
Operating temperature: 0...40°C
Measuring instrument features: 16 logic input channels; logic analyser; mathematical functions: addition, subtraction, division, multiplication and FFT
Input impedance: 1MΩ/15pF
Supply voltage: 100...240V AC
Display resolution: 640x480
Body dimensions: 370x180x120mm
Power consumption: 18W
Sampling: 500Msps
Type of oscilloscope: digital
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Horizontal accuracy: ±3%
Trigger modes: automatic; normal; single
Trigger source: CH1; CH2; external signal
Trigger coupling: AC; DC; highpass; lowpass
Plug variant: EU
Kind of display used: LCD TFT 8"
Rise time: ≤3.5ns
Input sensitivity: 2mV/div...10V/div
Time base: 5n...100s/div
Software: included
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 100MHz; 8bit; LCD 3,8"; Ch: 2; 1Gsps; 6kpts
Display resolution: 640x480
Input impedance: 1MΩ/20pF
Related items: PKT-AKKU5
Standard equipment: case; oscilloscope probe x2; power supply; test leads; USB cable; user's manual
Additional functions: multimeter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); FFT analysis: Rectangular, Hamming, Hanning, Blackman-Harris; insulated inputs; mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; X-Y operation mode
Sampling: 1Gsps
Type of oscilloscope: handheld oscilloscope
Trigger: alternate; falling-edge; rising-edge; video signal
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger source: CH1; CH2
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 400V
Band: 100MHz
Rise time: ≤3.5ns
Input sensitivity: 5mV/div...5V/div
Time base: 5n...100s/div
Software: included
Memory record length: 6kpts
Kind of display used: LCD 3,8"
Power supply: mains power supply; rechargeable battery Li-Ion x1
Body dimensions: 180x115x40mm
Interface: USB
Number of channels: 2
Conform to the norm: CAT II 400V; EN 61010
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 20MHz; 8bit; LCD 3,8"; Ch: 2; 100Msps; 6kpts
Display resolution: 640x480
Input impedance: 1MΩ/20pF
Related items: PKT-AKKU5
Standard equipment: case; oscilloscope probe x2; power supply; test leads; USB cable; user's manual
Additional functions: multimeter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); FFT analysis: Rectangular, Hamming, Hanning, Blackman-Harris; mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; X-Y operation mode
Sampling: 100Msps
Type of oscilloscope: handheld oscilloscope
Trigger: alternate; falling-edge; rising-edge; video signal
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger source: CH1; CH2
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 400V
Band: 20MHz
Rise time: ≤17.5ns
Input sensitivity: 5mV/div...5V/div
Time base: 5n...100s/div
Software: included
Memory record length: 6kpts
Kind of display used: LCD 3,8"
Power supply: mains power supply; rechargeable battery Li-Ion x1
Body dimensions: 180x115x40mm
Interface: USB
Number of channels: 2
Conform to the norm: CAT II 400V; EN 61010
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 70MHz; 8bit; LCD 8"; Ch: 2; 1Gsps; 40pts
Body dimensions: 270x191x48mm
Interface: LAN; USB
Number of channels: 2
Conform to the norm: CAT II 400V; EN 61010
Display resolution: 800x600
Input impedance: 1MΩ/15pF
Standard equipment: BNC cable; oscilloscope probe x2; power supply; user's manual
Additional functions: multimeter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); FFT analysis: Rectangular, Hamming, Hanning, Blackman-Harris; mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; X-Y operation mode
Sampling: 1Gsps
Type of oscilloscope: handheld oscilloscope
Trigger: bus; falling-edge; impulse width; logic; Nth Edge; rising-edge; runt; slope; timeout; video signal; window
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger source: CH1; CH2
Max. input voltage: 400V
Band: 70MHz
Rise time: ≤5ns
Input sensitivity: 1mV/div...10V/div
Battery/ rechargeable battery: rechargeable battery Li-Ion 7,4V 8000mAh x1
Software: included
Memory record length: 40pts
Touchpad: yes
Kind of display used: LCD 8"
Power supply: mains power supply; rechargeable battery Li-Ion 7,4V 8000mAh x1
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 120MHz; 8bit; LCD 8"; Ch: 2; 1Gsps; 40pts
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); FFT analysis: Rectangular, Hamming, Hanning, Blackman-Harris; mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; X-Y operation mode
Kind of display used: LCD 8"
Power supply: mains power supply; rechargeable battery Li-Ion 7,4V 8000mAh x1
Standard equipment: BNC cable; oscilloscope probe x2; power supply; user's manual
Conform to the norm: CAT II 400V; EN 61010
Body dimensions: 270x191x48mm
Max. input voltage: 400V
Battery/ rechargeable battery: rechargeable battery Li-Ion 7,4V 8000mAh x1
Band: 120MHz
Rise time: ≤2.9ns
Input sensitivity: 1mV/div...10V/div
Software: included
Memory record length: 40pts
Touchpad: yes
Interface: LAN; USB
Number of channels: 2
Display resolution: 800x600
Input impedance: 1MΩ/15pF
Additional functions: multimeter
Sampling: 1Gsps
Type of oscilloscope: handheld oscilloscope
Trigger: bus; falling-edge; impulse width; logic; Nth Edge; rising-edge; runt; slope; timeout; video signal; window
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger source: CH1; CH2
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 70MHz; 8bit; LCD 8"; Ch: 4; 1Gsps; 40pts
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); FFT analysis: Rectangular, Hamming, Hanning, Blackman-Harris; mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; X-Y operation mode
Kind of display used: LCD 8"
Power supply: mains power supply; rechargeable battery Li-Ion 7,4V 8000mAh x1
Standard equipment: BNC cable; oscilloscope probe x3; power supply; user's manual
Conform to the norm: CAT II 400V; EN 61010
Body dimensions: 270x191x48mm
Max. input voltage: 400V
Battery/ rechargeable battery: rechargeable battery Li-Ion 7,4V 8000mAh x1
Band: 70MHz
Rise time: ≤5ns
Input sensitivity: 1mV/div...10V/div
Software: included
Memory record length: 40pts
Touchpad: yes
Interface: LAN; USB
Number of channels: 4
Display resolution: 800x600
Input impedance: 1MΩ/15pF
Additional functions: multimeter
Sampling: 1Gsps
Type of oscilloscope: handheld oscilloscope
Trigger: bus; falling-edge; impulse width; logic; Nth Edge; rising-edge; runt; slope; timeout; video signal; window
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger source: CH1; CH2; CH3; CH4
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 100MHz; 8bit; LCD 8"; Ch: 4; 1Gsps; 40pts
Body dimensions: 270x191x48mm
Interface: LAN; USB
Number of channels: 4
Conform to the norm: CAT II 400V; EN 61010
Display resolution: 800x600
Input impedance: 1MΩ/15pF
Standard equipment: BNC cable; oscilloscope probe x3; power supply; user's manual
Additional functions: multimeter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); FFT analysis: Rectangular, Hamming, Hanning, Blackman-Harris; mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; X-Y operation mode
Sampling: 1Gsps
Type of oscilloscope: handheld oscilloscope
Trigger: bus; falling-edge; impulse width; logic; Nth Edge; rising-edge; runt; slope; timeout; video signal; window
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger source: CH1; CH2; CH3; CH4
Max. input voltage: 400V
Band: 100MHz
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Battery/ rechargeable battery: rechargeable battery Li-Ion 7,4V 8000mAh x1
Software: included
Memory record length: 40pts
Touchpad: yes
Kind of display used: LCD 8"
Power supply: mains power supply; rechargeable battery Li-Ion 7,4V 8000mAh x1
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 20MHz; 8bit; LCD 3,8"; Ch: 1; 100Msps; 6kpts
Body dimensions: 115x180x40mm
Interface: USB
Additional functions: multimeter
Software: included
Display resolution: 640x480
Power supply: mains power supply; rechargeable battery Li-Ion x1
Input impedance: 1MΩ/20pF
Related items: PKT-AKKU5
Standard equipment: case; oscilloscope probe x2; power supply; test leads; USB cable; user's manual
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); FFT analysis: Rectangular, Hamming, Hanning, Blackman-Harris; mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; X-Y operation mode
Sampling: 100Msps
Type of oscilloscope: handheld oscilloscope
Trigger: alternate; falling-edge; rising-edge; video signal
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger source: CH1; CH2
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 400V
Kind of display used: LCD 3,8"
Band: 20MHz
Rise time: ≤17.5ns
Input sensitivity: 5mV/div...5V/div
Time base: 5n...100s/div
Memory record length: 6kpts
Number of channels: 1
Conform to the norm: CAT II 400V; EN 61010
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 200MHz; 1Gsps; 2Mpts/ch; LCD TFT 8"
Interface: USB
Max. input voltage: 400V
Number of channels: 2
Standard equipment: BNC cable x2; case; logic probe; mains cable; oscilloscope probe x2; USB cable; user's manual
Trigger: alternate; falling-edge; pulse; rising-edge; slope; video signal
Memory record length: 2Mpts/ch
Band: 200MHz
Operating temperature: 0...40°C
Measuring instrument features: 16 logic input channels; logic analyser; mathematical functions: addition, subtraction, division, multiplication and FFT
Input impedance: 1MΩ/15pF
Supply voltage: 100...240V AC
Display resolution: 640x480
Body dimensions: 370x180x120mm
Power consumption: 18W
Sampling: 1Gsps
Type of oscilloscope: digital
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Horizontal accuracy: ±3%
Trigger modes: automatic; normal; single
Trigger source: CH1; CH2; external signal
Trigger coupling: AC; DC; highpass; lowpass
Plug variant: EU
Kind of display used: LCD TFT 8"
Rise time: ≤1.75ns
Input sensitivity: 2mV/div...10V/div
Time base: 1n...100s/div
Software: included
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 60MHz; 250Msps; 10Mpts; LCD TFT 8"
Kind of display used: LCD TFT 8"
Display resolution: 800x600
Sampling: 250Msps
Number of channels: 2
Interface: LAN; USB; VGA
Software: included
Plug variant: EU
Operating temperature: 0...40°C
Body dimensions: 348x170x78mm
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT; Pass/Fail function
Standard equipment: mains cable; oscilloscope probe x2; test adapter; USB cable; user's manual
Related items: PKT-AKKU3
Memory record length: 10Mpts
Supply voltage: 100...240V AC
Power consumption: 18W
Input impedance: 1MΩ/10pF
Type of oscilloscope: digital
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Horizontal accuracy: ±3%
Trigger modes: automatic; normal; single
Trigger source: CH1; CH2; external signal
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 400V
Band: 60MHz
Rise time: ≤5.8ns
Input sensitivity: 2mV/div...10V/div
Time base: 5n...100s/div
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 500Msps; 10Mpts; LCD TFT 8"
Kind of display used: LCD TFT 8"
Display resolution: 800x600
Sampling: 500Msps
Number of channels: 2
Interface: LAN; USB; VGA
Software: included
Plug variant: EU
Operating temperature: 0...40°C
Body dimensions: 348x170x78mm
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT; Pass/Fail function
Standard equipment: mains cable; oscilloscope probe x2; test adapter; USB cable; user's manual
Related items: PKT-AKKU3
Memory record length: 10Mpts
Supply voltage: 100...240V AC
Power consumption: 18W
Input impedance: 1MΩ/10pF
Type of oscilloscope: digital
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Horizontal accuracy: ±3%
Trigger modes: automatic; normal; single
Trigger source: CH1; CH2; external signal
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 400V
Band: 100MHz
Rise time: ≤3.5ns
Input sensitivity: 2mV/div...10V/div
Time base: 2n...100s/div
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 10Mpts; LCD TFT 8"
Power consumption: 18W
Body dimensions: 348x170x78mm
Operating temperature: 0...40°C
Supply voltage: 100...240V AC
Interface: LAN; USB; VGA
Software: included
Display resolution: 800x600
Input impedance: 1MΩ/10pF
Related items: PKT-AKKU3
Standard equipment: mains cable; oscilloscope probe x2; test adapter; USB cable; user's manual
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT; Pass/Fail function
Sampling: 1Gsps
Type of oscilloscope: digital
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Horizontal accuracy: ±3%
Trigger modes: automatic; normal; single
Trigger source: CH1; CH2; external signal
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 400V
Plug variant: EU
Kind of display used: LCD TFT 8"
Band: 100MHz
Rise time: ≤1.7ns
Input sensitivity: 2mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 10Mpts
Number of channels: 2
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 200MHz; 1Gsps; 10Mpts; LCD TFT 8"
Kind of display used: LCD TFT 8"
Display resolution: 800x600
Sampling: 1Gsps
Number of channels: 2
Interface: LAN; USB; VGA
Software: included
Plug variant: EU
Operating temperature: 0...40°C
Body dimensions: 348x170x78mm
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT; Pass/Fail function
Standard equipment: mains cable; oscilloscope probe x2; test adapter; USB cable; user's manual
Related items: PKT-AKKU3
Memory record length: 10Mpts
Supply voltage: 100...240V AC
Power consumption: 18W
Input impedance: 1MΩ/10pF
Type of oscilloscope: digital
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Horizontal accuracy: ±3%
Trigger modes: automatic; normal; single
Trigger source: CH1; CH2; external signal
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 400V
Band: 200MHz
Rise time: ≤1.7ns
Input sensitivity: 2mV/div...10V/div
Time base: 1n...100s/div
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 30MHz; 125Msps; 10kpts; LCD TFT 8"
Kind of display used: LCD TFT 8"
Display resolution: 800x600
Sampling: 125Msps
Number of channels: 2
Interface: LAN; USB; VGA
Software: included
Plug variant: EU
Operating temperature: 0...40°C
Body dimensions: 348x170x78mm
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT; Pass/Fail function
Standard equipment: mains cable; oscilloscope probe x2; test adapter; USB cable; user's manual
Memory record length: 10kpts
Supply voltage: 100...240V AC
Power consumption: 15W
Input impedance: 1MΩ/10pF
Type of oscilloscope: digital
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Horizontal accuracy: ±3%
Trigger modes: automatic; normal; single
Trigger source: CH1; CH2; external signal
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 400V
Band: 30MHz
Rise time: ≤11ns
Input sensitivity: 5mV/div...5V/div
Time base: 4n...100s/div
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 300MHz; 1,25Gsps; 10Mpts; LCD TFT 8"
Kind of display used: LCD TFT 8"
Display resolution: 800x600
Sampling: 1,25Gsps
Number of channels: 2
Interface: LAN; USB; VGA
Software: included
Plug variant: EU
Operating temperature: 0...40°C
Body dimensions: 348x170x78mm
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT; Pass/Fail function
Standard equipment: mains cable; oscilloscope probe x2; test adapter; USB cable; user's manual
Related items: PKT-AKKU3
Memory record length: 10Mpts
Supply voltage: 100...240V AC
Power consumption: 18W
Input impedance: 1MΩ/10pF
Type of oscilloscope: digital
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Horizontal accuracy: ±3%
Trigger modes: automatic; normal; single
Trigger source: CH1; CH2; external signal
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 400V
Band: 300MHz
Rise time: ≤1.17ns
Input sensitivity: 2mV/div...10V/div
Time base: 1n...100s/div
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 300MHz; 1,6Gsps; 10Mpts; LCD TFT 8"
Kind of display used: LCD TFT 8"
Display resolution: 800x600
Sampling: 1,6Gsps
Number of channels: 2
Interface: LAN; USB; VGA
Software: included
Plug variant: EU
Operating temperature: 0...40°C
Body dimensions: 348x170x78mm
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT; Pass/Fail function
Standard equipment: mains cable; oscilloscope probe x2; test adapter; USB cable; user's manual
Related items: PKT-AKKU3
Memory record length: 10Mpts
Supply voltage: 100...240V AC
Power consumption: 18W
Input impedance: 1MΩ/10pF
Type of oscilloscope: digital
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Horizontal accuracy: ±3%
Trigger modes: automatic; normal; single
Trigger source: CH1; CH2; external signal
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 400V
Band: 300MHz
Rise time: ≤1.17ns
Input sensitivity: 2mV/div...10V/div
Time base: 1n...100s/div
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: PC connected oscilloscopes
Description: PC connected oscilloscope; 60MHz; Ch: 2; 10Mpts; 250Msps; 1MΩ/10pF
Dimensions: 190x120x18mm
Measuring instrument features: FFT analysis: Rectangular, Hamming, Hanning, Blackman-Harris; mathematical functions: addition, subtraction, division, multiplication and FFT; Pass/Fail function
Standard equipment: case; oscilloscope probe x2; power supply; USB cable; user's manual
Interface: LAN; USB
Software: included
Sampling: 250Msps
Number of channels: 2
Band: 60MHz
Rise time: ≤5.8ns
Input sensitivity: 5mV/div...5V/div
Memory record length: 10Mpts
Converter resolution: 8bit
Input impedance: 1MΩ/10pF
Type of oscilloscope: PC connected oscilloscope
Input coupling: AC, DC, GND
Trigger modes: automatic; normal; single
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: PC connected oscilloscopes
Description: PC connected oscilloscope; 100MHz; Ch: 2; 10Mpts; 500Msps; ≤3.5ns
Sampling: 500Msps
Number of channels: 2
Interface: LAN; USB; USB Host
Software: included
Dimensions: 120x18x190mm
Measuring instrument features: FFT analysis: Rectangular, Hamming, Hanning, Blackman-Harris; mathematical functions: addition, subtraction, division, multiplication and FFT; Pass/Fail function
Standard equipment: case; oscilloscope probe x2; power supply; USB cable; user's manual
Memory record length: 10Mpts
Converter resolution: 8bit
Input impedance: 1MΩ/15pF
Type of oscilloscope: PC connected oscilloscope
Input coupling: AC, DC, GND
Trigger modes: automatic; normal; single
Band: 100MHz
Rise time: ≤3.5ns
Input sensitivity: 2mV/div...5V/div
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: PC connected oscilloscopes
Description: PC connected oscilloscope; 25MHz; Ch: 2; 5kpts; 100Msps; 1MΩ/10pF
Dimensions: 190x120x18mm
Standard equipment: case; oscilloscope probe x2; USB cable; user's manual
Interface: USB
Converter resolution: 8bit
Number of channels: 2
Input impedance: 1MΩ/10pF
Measuring instrument features: FFT analysis: Rectangular, Hamming, Hanning, Blackman-Harris; mathematical functions: addition, subtraction, division, multiplication and FFT; Pass/Fail function
Sampling: 100Msps
Type of oscilloscope: PC connected oscilloscope
Input coupling: AC, DC, GND
Trigger modes: automatic; normal; single
Band: 25MHz
Rise time: ≤14ns
Input sensitivity: 5mV/div...5V/div
Software: included
Memory record length: 5kpts
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 7.6Mpts/ch; LCD TFT 8"
Body dimensions: 380x180x115mm
Operating temperature: 0...40°C
Power consumption: 24W
Plug variant: EU
Standard equipment: mains cable; oscilloscope probe x4; USB cable; user's manual
Interface: LAN; USB; VGA
Number of channels: 4
Display resolution: 800x600
Input impedance: 1MΩ/10pF
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT; Pass/Fail function
Sampling: 1Gsps
Type of oscilloscope: digital
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Horizontal accuracy: ±3%
Trigger modes: automatic; normal; single
Trigger source: CH1; CH2; CH3; CH4; line
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 400V
Band: 100MHz
Rise time: ≤3.5ns
Input sensitivity: 2mV/div...10V/div
Time base: 2n...100s/div
Software: included
Memory record length: 7.6Mpts/ch
Kind of display used: LCD TFT 8"
Supply voltage: 100...240V AC
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 200MHz; 2Gsps; 7.6Mpts/ch; LCD TFT 8"
Kind of display used: LCD TFT 8"
Display resolution: 800x600
Sampling: 2Gsps
Number of channels: 4
Interface: LAN; USB; VGA
Software: included
Plug variant: EU
Operating temperature: 0...40°C
Body dimensions: 380x180x115mm
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT; Pass/Fail function
Standard equipment: mains cable; oscilloscope probe x4; USB cable; user's manual
Memory record length: 7.6Mpts/ch
Supply voltage: 100...240V AC
Power consumption: 24W
Input impedance: 1MΩ/10pF
Type of oscilloscope: digital
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Horizontal accuracy: ±3%
Trigger modes: automatic; normal; single
Trigger source: CH1; CH2; CH3; CH4; line
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 400V
Band: 200MHz
Rise time: ≤1.7ns
Input sensitivity: 2mV/div...10V/div
Time base: 2n...100s/div
Anzahl je Verpackung: 1 Stücke

Hersteller: PEAKTECH
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 70MHz; 500Msps; 100kpts; LCD TFT 8"
Kind of display used: LCD TFT 8"
Display resolution: 800x600
Sampling: 500Msps
Number of channels: 2
Interface: LAN; USB; VGA
Software: included
Plug variant: EU
Operating temperature: 0...40°C
Body dimensions: 348x170x78mm
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT; Pass/Fail function
Standard equipment: mains cable; oscilloscope probe x2; test adapter; USB cable; user's manual
Memory record length: 100kpts
Supply voltage: 100...240V AC
Power consumption: 15W
Input impedance: 1MΩ/15pF
Type of oscilloscope: digital
Trigger: alternate; falling-edge; pulse; rising-edge; slope; video signal
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Horizontal accuracy: ±3%
Trigger modes: automatic; normal; single
Trigger source: CH1; CH2; external signal
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 400V
Band: 70MHz
Rise time: ≤5ns
Input sensitivity: 5mV/div...5V/div
Time base: 2n...100s/div
Anzahl je Verpackung: 1 Stücke
