Hersteller: FLUKE
Category: Indicators, Voltage & Continuity Testers
Description: Tester: electrical; LCD; VAC: 1÷1000V; VDC: 1÷1000V; I AC: 200A; IP52
Type of tester: electrical
Kind of display used: LCD
AC voltage measuring range: 1...1000V
AC voltage measuring accuracy: ±(1.5% + 2 digit)
DC voltage measuring range: 1...1000V
DC voltage measuring accuracy: ±(1% + 2 digit)
AC current measuring range: 200A
AC current measuring accuracy: ±(3% + 3 digit)
True effective value measurement: True RMS
Resistance measuring range: 2kΩ; 20kΩ; 100kΩ
Resistance measuring accuracy: ±(1%+2 digit)
Continuity test: acoustic indication
Measurement frequency: 45...66Hz
IP rating: IP52
Resistance to: fall from 3m height
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Power supply: battery LR6 AA 1,5V x2
Measuring instrument features: autoranging; FieldSense - non-contact measurement of voltage, current and frequency; HOLD function
Standard equipment: test leads
Optional equipment: crocodile clip FLK-AC220; crocodile clip FLK-AC285
Body dimensions: 61.1x259.3x43.8mm
Weight with battery: 499g
Producer guarantee (months): 24
Related items: POM-5912B; POM-6041B; POM-6232A
Battery/ rechargeable battery: battery LR6 AA 1,5V x2
Illumination: yes

Hersteller: FLUKE
Category: Batteries Testers
Description: Tester: batteries and rechargeable batteries; 220x103x58mm
Type of tester: batteries and rechargeable batteries
DC voltage measuring range: 1mV...6V; 60V; 600V; 1kV
Dimensions: 220x103x58mm
IP rating: IP40
Plug variant: EU
Battery/ rechargeable battery: rechargeable battery Li-Ion 7,4V 3000mAh x1
Related items: FLK-BP500
Measurement: DC voltage; resistance
Resistance measuring range: 0.001...3mΩ; 30mΩ; 300mΩ; 3Ω
Interface: USB
Conform to the norm: CAT III 600V; EN 61010
Standard equipment: 0 Ω calibration resistor; Calibration board; carrying case; case; CD with documentation; Charger FLK-BC-500; magnetic hanging strap FLK-TOOLPAK; mains cable; shoulder strap; test leads; USB A / USB B-mini cable
Measuring resolution: 0,001/0,01/0,1/1V; 0,001/0,01/0,1/1Ω

Hersteller: FLUKE
Category: Batteries Testers
Description: Tester: batteries and rechargeable batteries; 220x103x58mm
Type of tester: batteries and rechargeable batteries
DC voltage measuring range: 1mV...6V; 60V; 600V; 1kV
Resistance measuring range: 0.001...3mΩ; 30mΩ; 300mΩ; 3Ω
Standard equipment: 0 Ω calibration resistor; BTL20 intelligent test probe set with extender (no temperature sensor); Calibration board; carrying case; case; CD with documentation; Charger FLK-BC-500; magnetic hanging strap FLK-TOOLPAK; mains cable; shoulder strap; test leads; USB A / USB B-mini cable
Conform to the norm: CAT III 600V; EN 61010
IP rating: IP40
Related items: FLK-BP500
Measurement: DC voltage; resistance
Battery/ rechargeable battery: rechargeable battery Li-Ion 7,4V 3000mAh x1
Interface: USB
Dimensions: 220x103x58mm
Plug variant: EU
Measuring resolution: 0,001/0,01/0,1/1V; 0,001/0,01/0,1/1Ω

Hersteller: FLUKE
Category: Batteries Testers
Description: Tester: batteries and rechargeable batteries; 220x103x58mm
Type of tester: batteries and rechargeable batteries
AC current measuring accuracy: ±(3.5% + 2 digit)
AC current measuring range: 1...400A
DC voltage measuring range: 1mV...6V; 60V; 600V; 1kV
DC current measuring accuracy: ±(3.5% + 2 digit)
DC current measuring range: 1...400A
Resistance measuring range: 0.001...3mΩ; 30mΩ; 300mΩ; 3Ω
Standard equipment: 0 Ω calibration resistor; BTL21 intelligent test probe set with extender and temperature sensor; Calibration board; carrying case; case; CD with documentation; Charger FLK-BC-500; FLK-I410 - current clamp; magnetic hanging strap FLK-TOOLPAK; mains cable; shoulder strap; test leads; USB A / USB B-mini cable
Conform to the norm: CAT III 600V; EN 61010
IP rating: IP40
Related items: FLK-BP500
Measurement: AC current; DC current; DC voltage; resistance; temperature of negative battery post
Battery/ rechargeable battery: rechargeable battery Li-Ion 7,4V 3000mAh x1
Interface: Bluetooth; USB
Dimensions: 220x103x58mm
Plug variant: EU
Software: Fluke Battery Analyzer
Measuring resolution: 0,001/0,01/0,1/1V; 0,001/0,01/0,1/1Ω
Current measuring resolution: 1A

Hersteller: FLUKE
Category: Voltage and Current Loggers
Description: Data logger; harmonics; ±0,5% ; 134x77x39mm; Interface: USB
Type of meter: data logger
Measurement: harmonics
Measurement accuracy: ±0,5%
Standard equipment: adapters for supply cord; USB cable
Body dimensions: 134x77x39mm
Interface: USB
Conform to the norm: CAT II 300V; EN 61010
Plug variant: EU
Measuring range: 70...300V
Measuring resolution: 0,125 V
Resistance to: fall from 1m height
Pollution degree: 2
Measuring instrument features: continuous logging of all values without any stops; memory built-in; MIN/MAX/MEDIUM function; quick logging of voltage tendencies, fading and energy quality; statistical analysis of single phase voltage events
Software: Fluke Power Log
Connectors for the country: Great Britain
Supply voltage: 70...300V AC

Hersteller: FLUKE
Category: Accessories - Others
Description: LED torch
Power supply: battery CR1620 3V x2
Type of test accessories: LED torch
Measuring instrument features: small, rugged light easily attaches to any Fluke test probe

Hersteller: FLUKE
Category: Accessories - Others
Description: LED torch
Power supply: battery CR1620 3V x2
Type of test accessories: LED torch
Measuring instrument features: 20cm probe extenders; small, rugged light easily attaches to any Fluke test probe

Hersteller: FLUKE
Category: Fluke Infrared Cameras
Description: Test acces: battery
Related items: Fluke FLEX CAM
Type of test accessories: battery

Hersteller: FLUKE
Category: Insulation Resistance Meters
Description: Meter: insulation resistance; LCD; VAC: 100mV÷600V; 50÷400Hz; IP40
Related items: POM-5674C; POM-5907A; POM-6041B
Body dimensions: 203x100x50mm
Illumination: yes
Standard equipment: crocodile clips; FLK-TL224 silicone test leads set; FLK-TP74 lamel tip test probes; test probe FLK-TP165X
Measuring instrument features: automatic discharge of capacitance charge function; automatic power-off; insulation test stop function in case of detection of voltage over 30V; pushbutton-controlled test probe
Type of meter: insulation resistance
Weight with battery: 550g
Optional equipment: crocodile clip FLK-AC285; FLK-C25 soft cover; FLK-C101 hard case; FLK-TL81A accessory set; FLK-TL225 set; FLK-TOOLPAK strap with magnet for suspending the meter
Continuity test: acoustic indication
Capacitance discharge time: <0.5s
Automatic discharging capacitance: max. 1µF
Open circuit test voltage: 4...8V
Measurement: AC voltage; DC voltage; insulation resistance; resistance
Bandwidth for AC voltage measurements: 50...400Hz
Test voltage: 500V DC; 1kV DC
Resistance measuring range: 10mΩ...20Ω; 200Ω; 2kΩ; 20kΩ
DC voltage measuring range: 100mV...600V
AC voltage measuring range: 100mV...600V
Battery/ rechargeable battery: battery LR6 AA 1,5V x4
Insulation resistance measuring ranges: 10kΩ...20MΩ; 200MΩ; 500MΩ; 2GΩ
DC voltage measuring accuracy: ±(2% + 3 digit)
AC voltage measuring accuracy: ±(2% + 3 digit)
Resistance measuring accuracy: ±(1.5%+3 digit)
Insulation resistance measuring accuracy: ±(2% + 5digit)
Kind of display used: LCD
Power supply: battery LR6 AA 1,5V x4
IP rating: IP40
Conform to the norm: CAT IV 600V; EN 61010

Hersteller: FLUKE
Category: Insulation Resistance Meters
Description: Meter: insulation resistance; LCD; VAC: 100mV÷600V; 50÷400Hz; IP40
IP rating: IP40
Related items: POM-5674C; POM-5907A; POM-6041B
Body dimensions: 203x100x50mm
Conform to the norm: CAT IV 600V; EN 61010
Illumination: yes
Power supply: battery LR6 AA 1,5V x4
Kind of display used: LCD
Standard equipment: crocodile clips; FLK-TL224 silicone test leads set; FLK-TP74 lamel tip test probes; test probe FLK-TP165X
Measuring instrument features: automatic calculation of polarization index; automatic discharge of capacitance charge function; automatic power-off; automatic quotient of dielectric absorption function; comparison function for fast realisation of repeated tests; insulation test stop function in case of detection of voltage over 30V; pushbutton-controlled test probe; wide test voltages selection
Type of meter: insulation resistance
Weight with battery: 550g
Optional equipment: crocodile clip FLK-AC285; FLK-C25 soft cover; FLK-C101 hard case; FLK-TL81A accessory set; FLK-TL225 set; FLK-TOOLPAK strap with magnet for suspending the meter
Continuity test: acoustic indication
Capacitance discharge time: <0.5s
Automatic discharging capacitance: max. 1µF
Open circuit test voltage: 4...8V
Measurement: AC voltage; DC voltage; insulation resistance; resistance
Bandwidth for AC voltage measurements: 50...400Hz
Test voltage: 50V DC; 100V DC; 250V DC; 500V DC; 1kV DC
Resistance measuring range: 10mΩ...20Ω; 200Ω; 2kΩ; 20kΩ
DC voltage measuring range: 100mV...600V
AC voltage measuring range: 100mV...600V
Battery/ rechargeable battery: battery LR6 AA 1,5V x4
Insulation resistance measuring ranges: 10kΩ...20MΩ; 50MΩ; 100MΩ; 200MΩ; 500MΩ; 2GΩ; 10GΩ
DC voltage measuring accuracy: ±(2% + 3 digit)
AC voltage measuring accuracy: ±(2% + 3 digit)
Resistance measuring accuracy: ±(1.5%+3 digit)
Insulation resistance measuring accuracy: ±(1.5% + 5digit)

Hersteller: FLUKE
Category: Multimeters - Sets
Description: Measuring kit: multimeters
Related items: FLK-80BK-A; FLK-80PJ-1; FLK-80PJ-9; FLK-80PJ-EXT; FLK-80PK-1; FLK-80PK-3A; FLK-80PK-8; FLK-80PK-9; FLK-80PK-11; FLK-80PK-22; FLK-80PK-24; FLK-80PK-25; FLK-80PK-26; FLK-80PK-27; FLK-80PR-60; FLK-80PT-EXT; FLK-80T-150UA; POM-5904A/POM; POM-6343; POM-7519A
Standard equipment: clamp meter FLK-323; crocodile clips FLK-AC175; digital multimeter FLK-179; FLK-80BK-A drop-like K-type probe; FLK-TL75 test leads; user's manual
Type of measuring kit: multimeters
Battery/ rechargeable battery: battery 6LR61 9V x1; battery LR03 AAA 1,5V x2

Hersteller: FLUKE
Category: Portable digital multimeters
Description: Digital multimeter; LCD; (6000/20000); Bargraph: 33segm.40x/s
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Related items: FLK-80BK-A; FLK-80PJ-1; FLK-80PJ-9; FLK-80PJ-EXT; FLK-80PK-1; FLK-80PK-3A; FLK-80PK-8; FLK-80PK-9; FLK-80PK-11; FLK-80PK-22; FLK-80PK-24; FLK-80PK-25; FLK-80PK-26; FLK-80PK-27; FLK-80PR-60; FLK-80PT-EXT; FLK-80T-150UA; POM-4408; POM-5519A; POM-5673B
Illumination: yes
Standard equipment: crocodile clip FLK-AC175 x2; FLK-80BK-A drop-like K-type probe; FLK-I400 - current clamp; test leads TL75
Measuring instrument features: auto and manual ranging; automatic power-off; built-in thermometer; filter ensuring voltage and frequency measuring accuracy; HOLD function; impact resistant holster; indicates incorrect connection of test leads; MIN/MAX/MEDIUM function; PEAK HOLD function; test leads resistance compensation
Type of meter: digital multimeter
Continuity test: acoustic indication
Pollution degree: 2
Temperature measurement resolution: 0.1°C
Conductance measurement: 0.01...60nS
Temperature measuring range: -200...1090°C
True effective value measurement: True RMS AC
Bargraph: 33 segm. 40x/s
Measurement: AC current; AC voltage; capacitance; DC current; DC voltage; frequency; resistance; temperature
Dimensions (W x H x D): 63x198x100mm
AC current measuring range: 0.1...600µA; 6mA; 60mA; 400mA; 6A; 10A; (20A <30s)
Resistance measuring range: 100mΩ...600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 50MΩ
DC current measuring range: 0.1...600µA; 6mA; 60mA; 400mA; 6A; 10A; 20A < 30s
DC voltage measuring range: 0.1...600mV; 6V; 60V; 600V; 1kV
AC voltage measuring range: 0.1...600mV; 6V; 60V; 600V; 1kV
Frequency measuring range: 10mHz...199.99Hz; 1999.9Hz; 19.999kHz; 199.99kHz
Capacitance measuring range: 10pF...10nF; 100nF; 1µF; 10µF; 100µF; 9.999mF
Diode test: 1mA @3V
Display parameters: (6000/20000)
Frequency measuring accuracy: ±(0.005%+1 digit)
Capacitance measuring accuracy: ±(1%+ 2 digit)
AC current measuring accuracy: ±(1% + 2 digit)
DC voltage measuring accuracy: ±(0.05% + 1 digit)
DC current measuring accuracy: ±(0.2% + 4 digit)
AC voltage measuring accuracy: ±(0.7% + 4 digit)
Conductance measuring accuracy: ±(1% + 10digit)
Resistance measuring accuracy: ±(0.2%+1 digit)
Temperature measurement accuracy: ±(1% + 10 digit)
Kind of display used: LCD
Power supply: battery LR6 AA 1,5V x3
IP rating: IP67

Hersteller: FLUKE
Category: Accessories - Others
Description: Fuse; 25A; 250V; Ø6.3x32mm
Type of test accessories: fuse
Current rating: 25A
Rated voltage: 0.25kV
Dimensions: Ø6.3x32mm

Hersteller: FLUKE
Category: Accessories for Oscilloscopes - Others
Description: RS232 cable; Application: for PC communication
Type of test accessories: RS232 cable
Measuring instruments application: for PC communication

Hersteller: FLUKE
Category: Accessories for Oscilloscopes - Others
Description: Adapter; banana 4mm plug,BNC socket
Type of test accessories: adapter
Cable/adapter structure: banana 4mm plug; BNC socket

Hersteller: FLUKE
Category: Accessories for Oscilloscopes - Others
Description: Adapter; banana 4mm socket x2,BNC plug
Type of test accessories: adapter
Cable/adapter structure: banana 4mm socket x2; BNC plug

Hersteller: FLUKE
Category: Inspection Cameras, Boroscopes
Description: Inspection camera; Display: LCD 7"; 68°; Cam.res: 1200x720; 6GB
Type of meter: inspection camera
Kind of display used: LCD 7"
Camera resolution: 1200x720
IP rating: IP54; IP68 (probe)
Dimensions: 173.3x224.8mm
Weight with battery: 880g
Power supply: rechargeable battery Li-Ion 3,7V x1
Measuring instrument features: automatic image orientation; digital zoom x8; dual view camera, from forward and side of the probe; LED for measurement spot illumination
Standard equipment: battery charger/power supply; hand strap; HDMI cable; magnetic hanging strap; neckstrap; soft case; USB cable
Interface: HDMI; USB; WiFi
Resistance to: fall from 2m height
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Software: Fluke Connect
Supported formats: AVI; JPEG
Touchpad: yes
Memory capacity: 6GB
Probe diameter: 8.5mm
Cable length: 1.2m
Viewing angle: 68°

Hersteller: FLUKE
Category: Fluke Infrared Cameras
Description: Infrared camera; LCD 3,5"; 120x90; -20÷150°C; Focus: focus free
Type of meter: infrared camera
Kind of display used: LCD 3,5"
Camera resolution: 120x90
Temperature measuring range: -20...150°C
Temperature measurement accuracy: ±2%; ±2°C
Focusing: focus free
IP rating: IP54
Body dimensions: 89x127x25mm
Weight with battery: 233g
Power supply: rechargeable battery Li-Ion 3,7V x1
Measuring instrument features: AutoBlend function; compact design; IR-Fusion function to combine thermal and real images; multilanguage menu; picture-in-picture (PIP) function; radiometric measurements for detailed temperature analysis; transfer measurement data wireless
Standard equipment: case; hand strap; USB cable
Three-dimensional resolution: 7.6mrad
Interface: WiFi
Resistance to: fall from 1m height
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Display resolution: 320x240
Software: Fluke Connect
Supported formats: IS2; JPG
Touchpad: yes
Field of observation: 50° horizontal x 38° vertical
Optical resolution: 130:1

Hersteller: FLUKE
Category: Fluke Infrared Cameras
Description: Infrared camera; LCD 3,5"; 320x240; -20÷650°C; IP54; 1.85mrad
Type of meter: infrared camera
Kind of display used: LCD 3,5"
Camera resolution: 320x240
Temperature measuring range: -20...650°C
Temperature measurement accuracy: ±2%; ±2°C
Focusing: automatic; manual
IP rating: IP54
Dimensions: 277x122x167mm
Power supply: rechargeable battery Li-Ion 7,4V x2
Measuring instrument features: adjustable display illumination; adjustable emissivity;; AutoBlend function; colour alarms; date and time setting possibility; illumination lamp; IR-Fusion function to combine thermal and real images; radiometric measurements for detailed temperature analysis; temperature markers (min, max); voice and text message recorder; wide palette of colours; wireless communication with PC
Standard equipment: battery charger; case; hand strap; hard case; HDMI cable; microSD memory card; power supply; USB cable
Thermal sensitivity (NETD): <0.075 @ 30°C
Three-dimensional resolution: 1.85mrad
Measurement: temperature
Interface: USB; WiFi
Measuring unit: °C; °F
Resistance to: fall from 2m height
Related items: FLK-TI-SBP3
Battery/ rechargeable battery: rechargeable battery Li-Ion 7,4V x2
Display resolution: 640x480
Field of observation: 34° horizontal x 24° vertical

Hersteller: FLUKE
Category: Fluke Infrared Cameras
Description: Infrared camera; LCD 3,5"; 640x480; -20÷650°C; IP54; 0.93mrad
Type of meter: infrared camera
Kind of display used: LCD 3,5"
Camera resolution: 640x480
Temperature measuring range: -20...650°C
Temperature measurement accuracy: ±2%; ±2°C
Focusing: automatic; manual
IP rating: IP54
Dimensions: 277x122x167mm
Power supply: rechargeable battery Li-Ion 7,4V x2
Measuring instrument features: adjustable display illumination; adjustable emissivity;; AutoBlend function; colour alarms; date and time setting possibility; illumination lamp; IR-Fusion function to combine thermal and real images; radiometric measurements for detailed temperature analysis; temperature markers (min, max); voice and text message recorder; wide palette of colours; wireless communication with PC
Standard equipment: battery charger; case; hand strap; hard case; HDMI cable; microSD memory card; power supply; USB cable
Thermal sensitivity (NETD): <0.075 @ 30°C
Three-dimensional resolution: 0.93mrad
Interface: USB; WiFi
Related items: FLK-TI-SBP3
Battery/ rechargeable battery: rechargeable battery Li-Ion 7,4V x2
Field of observation: 34° horizontal x 24° vertical

Hersteller: FLUKE
Category: Fluke Infrared Cameras
Description: Infrared camera; 640x480; -10÷1000°C; Interface: WiFi
Type of meter: infrared camera
Camera resolution: 640x480
Temperature measuring range: -10...1000°C
Temperature measurement accuracy: ±2%; ±2°C
Power supply: rechargeable battery Li-Ion x1
Measuring instrument features: adjustable display illumination; adjustable emissivity;; AutoBlend function; colour alarms; date and time setting possibility; illumination lamp; IR-Fusion function to combine thermal and real images; radiometric measurements for detailed temperature analysis; temperature markers (min, max); voice and text message recorder; wide palette of colours; wireless communication with PC
Thermal sensitivity (NETD): <0.05 @ 30°C
Interface: WiFi
Battery/ rechargeable battery: rechargeable battery Li-Ion x1

Hersteller: FLUKE
Category: Fluke Infrared Cameras
Description: Infrared camera; LCD 3,5"; 120x90; -20÷150°C; Focus: FocusFree
Type of meter: infrared camera
Kind of display used: LCD 3,5"
Camera resolution: 120x90
Temperature measuring range: -20...150°C
Temperature measurement accuracy: ±2%; ±2°C
Focusing: FocusFree
IP rating: IP54
Dimensions: 26.7x10.1x14.5mm
Power supply: rechargeable battery Li-Ion x1
Measuring instrument features: adjustable emissivity; AutoBlend function; IR-Fusion function to combine thermal and real images; wireless communication with PC
Standard equipment: battery charger; case; power supply; USB cable
Thermal sensitivity (NETD): 60mK
Three-dimensional resolution: 7.6mrad
Measurement: temperature
Interface: USB; WiFi
Measuring unit: °C; °F
Resistance to: fall from 2m height
Battery/ rechargeable battery: rechargeable battery Li-Ion x1
Display resolution: 320x240
Field of observation: 50° horizontal x 38° vertical

Hersteller: FLUKE
Category: Probes - Test Plugs
Description: Kit of test probes
Type of test accessories: kit of test probes
Kit contents: 20cm test probe extenders; FLK-TP220 probe tip; foldable soft pouch with 6 pockets and hook-and-loop; probe light FLK-L200; test leads FLK-TL224

Hersteller: FLUKE
Category: Indicators, Voltage & Continuity Testers
Description: Tester: electrical; LCD; VAC: 1÷1000V; VDC: 1÷1000V; I AC: 200A; IP52
Type of tester: electrical
Kind of display used: LCD
AC voltage measuring range: 1...1000V
AC voltage measuring accuracy: ±(1.5% + 2 digit)
DC voltage measuring range: 1...1000V
DC voltage measuring accuracy: ±(1% + 2 digit)
AC current measuring range: 200A
AC current measuring accuracy: ±(3% + 3 digit)
True effective value measurement: True RMS
Resistance measuring range: 2kΩ; 20kΩ; 100kΩ
Resistance measuring accuracy: ±(1%+2 digit)
Continuity test: acoustic indication
Measurement frequency: 45...66Hz
IP rating: IP52
Resistance to: fall from 3m height
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Power supply: battery LR6 AA 1,5V x2
Measuring instrument features: autoranging; FieldSense - non-contact measurement of voltage, current and frequency; HOLD function
Standard equipment: crocodile clips FLK-AC285; holster FLK-HT-6; test leads
Optional equipment: crocodile clip FLK-AC220; crocodile clip FLK-AC285
Body dimensions: 61.1x259.3x43.8mm
Weight with battery: 499g
Producer guarantee (months): 24
Related items: POM-5912B; POM-6041B; POM-6232A
Battery/ rechargeable battery: battery LR6 AA 1,5V x2
Illumination: yes

Hersteller: FLUKE
Category: Bags & Soft Cases
Description: Cover
Type of test accessories: cover
Related items: FLK-T6-600; FLK-T6-600/UK; FLK-T6-1000; FLK-T6-1000/UK

Hersteller: FLUKE
Category: Hangers and uprights on wires
Description: Hanger for test leads; 10 slots for wires up to 8mm diameter
Dimensions: 279x89x32mm
Type of test accessories: hanger for test leads
Test accessories features: 10 slots for wires up to 8mm diameter

Hersteller: FLUKE
Category: Indicators, Voltage & Continuity Testers
Description: Tester: electrical; LCD; (1000); VAC: 1÷1000V; VDC: 1÷1000V; IP52
Type of tester: electrical
Kind of display used: LCD
Display parameters: (1000)
Measurement: AC current; AC voltage; DC voltage; resistance
AC voltage measuring range: 1...1000V
AC voltage measuring accuracy: ±(1.5% + 2 digit)
DC voltage measuring range: 1...1000V
DC voltage measuring accuracy: ±(1% + 1 digit)
AC current measuring range: 100mA...100A
True effective value measurement: True RMS AC
Resistance measuring range: 1...1000Ω
Resistance measuring accuracy: ±(1%+2 digit)
Continuity test: 0Ω...400kΩ
IP rating: IP52
Resistance to: fall from 3m height
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Power supply: battery LR6 AA 1,5V x2
Measuring instrument features: automatic power-off; autoranging; compact design with compartment for test leads; easy current measurement due to open-jaw technology; measures automatically AC/DC with precise resolution
Standard equipment: test leads
Optional equipment: FLK-C33 soft cover; FLK-H5 belt holster
Body dimensions: 203x51x30.5mm
Weight with battery: 380g
Related items: POM-5912B; POM-6041B; POM-6232A
Battery/ rechargeable battery: battery LR6 AA 1,5V x2

Hersteller: FLUKE
Category: Multimeters for Electrical Installations
Description: Meter: appliance meter; LCD; RCD test: general purpose; FLK-1660
Type of meter: appliance meter
AC voltage measuring accuracy: ±(0.8% + 3 digit)
AC voltage measuring range: 100mV...500V
Insulation resistance measuring ranges: 10kΩ...100MΩ; 200MΩ; 500MΩ; 1GΩ
Earthing resistance measuring accuracy: ±(2% + 5 digit)
Standard equipment: 3 crocodile clips; carrying strap; test leads; test mains cable; test probe FLK-TP165X; TL-L1 red test lead; TL-L2 blue test lead; TL-L2 green test lead; user's manual
Measuring instrument features: checks conductors polarization
Kind of display used: LCD
Measurement: AC voltage; frequency; insulation resistance; RCD tripping current; RCD tripping time
Battery/ rechargeable battery: battery LR6 AA 1,5V x6
Power supply: battery LR6 AA 1,5V x6
Body dimensions: 100x250x125mm
RCD test: general purpose
Plug variant: EU
Illumination: yes
Manufacturer series: FLK-1660
Test voltage: 100V; 250V; 500V; 1kV

Hersteller: FLUKE
Category: Multimeters for Electrical Installations
Description: Meter: appliance meter; LCD; Earthing R range: 100mΩ÷200Ω,2kΩ
Body dimensions: 100x250x125mm
Manufacturer series: FLK-1660
Test voltage: 50V; 100V; 250V; 500V; 1kV
AC voltage measuring range: 100mV...500V
Earthing resistance measuring range: 100mΩ...200Ω; 2kΩ
Battery/ rechargeable battery: battery LR6 AA 1,5V x6
Insulation resistance measuring ranges: 10kΩ...50MΩ; 100MΩ; 200MΩ; 500MΩ; 1GΩ
AC voltage measuring accuracy: ±(0.8% + 3 digit)
Earthing resistance measuring accuracy: ±(2% + 5 digit)
Kind of display used: LCD
Power supply: battery LR6 AA 1,5V x6
Illumination: yes
Standard equipment: 3 crocodile clips; carrying strap; test adapter FLK-FEV300/TY2; test leads; test mains cable; test probe FLK-TP165X; TL-L1 red test lead; TL-L2 blue test lead; TL-L2 green test lead; user's manual
Measuring instrument features: checks conductors polarization
Type of meter: appliance meter
RCD test: general purpose
Plug variant: EU
Measurement: AC voltage; earthing resistance; frequency; insulation resistance; RCD tripping current; RCD tripping time

Hersteller: FLUKE
Category: Power Quality Analyzers
Description: Meter: power logger; colour,LCD TFT 4,3"; Network: three-phase
Type of meter: power logger
Measuring instrument features: memory built-in; sampling rate: every 1s, 5s, 10s, 30s, 1min., 5min., 10min., 15min., 30min.; transfer measurement data wireless
Kind of display used: colour; LCD TFT 4,3"
Display resolution: 480x272
Operating temperature: -10...50°C
Dimensions: 198x167x90mm
Power supply: from tested wiring system; mains power supply; rechargeable battery Li-Ion x1
Standard equipment: aligator clip x4; FLK-i17XX-FLEX1500 - current clamp; test leads; USB cable
Measurement: AC current; active power; AC voltage; apparent power; energy; frequency; harmonics; reactive power
Interface: USB A; WiFi (option)
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Software: Fluke Energy Analyze Plus
Battery/ rechargeable battery: rechargeable battery Li-Ion x1
IP rating: IP50
Kind of network: three-phase
Weight with battery: 1.1kg
Touchpad: yes

Hersteller: FLUKE
Category: Power Quality Analyzers
Description: Meter: power logger; colour,LCD TFT 4,3"; Network: three-phase
Type of meter: power logger
Measuring instrument features: memory built-in; sampling rate: every 1s, 5s, 10s, 30s, 1min., 5min., 10min., 15min., 30min.; transfer measurement data wireless
Kind of display used: colour; LCD TFT 4,3"
Display resolution: 480x272
Operating temperature: -10...50°C
Dimensions: 198x167x90mm
Power supply: from tested wiring system; mains power supply; rechargeable battery Li-Ion x1
Standard equipment: aligator clip x4; test leads; USB cable
Measurement: AC current; active power; AC voltage; apparent power; energy; frequency; harmonics; reactive power
Interface: USB A; WiFi (option)
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Software: Fluke Energy Analyze Plus
Battery/ rechargeable battery: rechargeable battery Li-Ion x1
IP rating: IP50
Kind of network: three-phase
Weight with battery: 1.1kg
Touchpad: yes

Hersteller: FLUKE
Category: Power Quality Analyzers
Description: Meter: power logger; colour,LCD TFT 4,3"; Network: three-phase
Type of meter: power logger
Measuring instrument features: memory built-in; sampling rate: every 1s, 5s, 10s, 30s, 1min., 5min., 10min., 15min., 30min.; transfer measurement data wireless
Kind of display used: colour; LCD TFT 4,3"
Display resolution: 480x272
Operating temperature: -10...50°C
Dimensions: 198x167x90mm
Power supply: from tested wiring system; mains power supply; rechargeable battery Li-Ion x1
Standard equipment: aligator clip x4; FLK-i17XX-FLEX1500 - current clamp; MP1 magnet probe; test leads; USB cable
Measurement: AC current; active power; AC voltage; apparent power; energy; frequency; harmonics; reactive power
Interface: Bluetooth (option); USB A; WiFi (option)
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Software: Fluke Connect; Fluke Energy Analyze Plus
Battery/ rechargeable battery: rechargeable battery Li-Ion x1
IP rating: IP50
Kind of network: three-phase
Weight with battery: 1.1kg
Touchpad: yes

Hersteller: FLUKE
Category: Power Quality Analyzers
Description: Meter: power logger; colour,LCD TFT 4,3"; Network: three-phase
Type of meter: power logger
Measuring instrument features: memory built-in; sampling rate: every 1s, 5s, 10s, 30s, 1min., 5min., 10min., 15min., 30min.; transfer measurement data wireless
Kind of display used: colour; LCD TFT 4,3"
Display resolution: 480x272
Operating temperature: -10...50°C
Dimensions: 198x167x90mm
Power supply: from tested wiring system; mains power supply; rechargeable battery Li-Ion x1
Standard equipment: aligator clip x4; MP1 magnet probe; test leads; USB cable
Measurement: AC current; active power; AC voltage; apparent power; energy; frequency; harmonics; reactive power
Interface: USB A; WiFi (option)
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Software: Fluke Energy Analyze Plus
Battery/ rechargeable battery: rechargeable battery Li-Ion x1
IP rating: IP50
Kind of network: three-phase
Weight with battery: 1.1kg
Touchpad: yes

Hersteller: FLUKE
Category: Power Quality Analyzers
Description: Meter: power logger; colour,LCD TFT 4,3"; Network: three-phase
Plug variant: EU
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
IP rating: IP50
Operating temperature: -10...50°C
Kind of network: three-phase
Interface: Bluetooth; USB; WiFi
Display resolution: 480x272
Dimensions: 198x167x90mm
Standard equipment: adapter WiFi; aligator clip x4; bluetooth adapter; FLK-i17XX-FLEX1500 - current clamp; mains cable; test leads; USB cable
Measuring instrument features: memory built-in; sampling rate: every 1s, 5s, 10s, 30s, 1min., 5min., 10min., 15min., 30min.; transfer measurement data wireless
Type of meter: power logger
Weight with battery: 1.1kg
Measurement: AC current; active power; AC voltage; apparent power; energy; frequency; harmonics; reactive power
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Software: Fluke Energy Analyze Plus
Touchpad: yes
Kind of display used: colour; LCD TFT 4,3"
Power supply: from tested wiring system; mains power supply; rechargeable battery Li-Ion 3,7V x1

Hersteller: FLUKE
Category: Power Quality Analyzers
Description: Meter: power logger; colour,LCD TFT 4,3"; Network: three-phase
Plug variant: EU
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
IP rating: IP50
Operating temperature: -10...50°C
Kind of network: three-phase
Interface: USB A; WiFi (option)
Display resolution: 480x272
Dimensions: 198x167x90mm
Standard equipment: aligator clip x4; test leads; USB cable
Measuring instrument features: memory built-in; sampling rate: every 1s, 5s, 10s, 30s, 1min., 5min., 10min., 15min., 30min.; transfer measurement data wireless
Type of meter: power logger
Weight with battery: 1.1kg
Measurement: AC current; active power; AC voltage; apparent power; energy; frequency; harmonics; reactive power
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Software: Fluke Energy Analyze Plus
Touchpad: yes
Kind of display used: colour; LCD TFT 4,3"
Power supply: from tested wiring system; mains power supply; rechargeable battery Li-Ion 3,7V x1

Hersteller: FLUKE
Category: Power Quality Analyzers
Description: Meter: power logger; colour,LCD TFT 4,3"; Network: three-phase
Type of meter: power logger
Kind of display used: colour; LCD TFT 4,3"
Kind of network: three-phase
Display resolution: 480x272
Measurement: AC current; active power; AC voltage; apparent power; energy; frequency; harmonics; reactive power
Interface: Bluetooth; USB; WiFi
Measuring instrument features: memory built-in; sampling rate: every 1s, 5s, 10s, 30s, 1min., 5min., 10min., 15min., 30min.; transfer measurement data wireless
Standard equipment: aligator clip x4; FLK-i17XX-FLEX1500 - current clamp; test leads; USB cable
Power supply: from tested wiring system; mains power supply; rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Dimensions: 198x167x90mm
Weight with battery: 1.1kg
IP rating: IP50
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Operating temperature: -10...50°C
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Software: Fluke Connect; Fluke Energy Analyze Plus
Touchpad: yes

Hersteller: FLUKE
Category: Power Quality Analyzers
Description: Meter: power logger; colour,LCD TFT 4,3"; Network: three-phase
Type of meter: power logger
Kind of display used: colour; LCD TFT 4,3"
Kind of network: three-phase
Display resolution: 480x272
Measurement: AC current; active power; AC voltage; apparent power; energy; frequency; harmonics; reactive power
Interface: Bluetooth (option); USB A; WiFi (option)
Measuring instrument features: memory built-in; sampling rate: every 1s, 5s, 10s, 30s, 1min., 5min., 10min., 15min., 30min.; transfer measurement data wireless
Standard equipment: aligator clip x4; test leads; USB cable
Power supply: from tested wiring system; mains power supply; rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Dimensions: 198x167x90mm
Weight with battery: 1.1kg
IP rating: IP50
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Operating temperature: -10...50°C
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Software: Fluke Connect
Touchpad: yes

Hersteller: FLUKE
Category: Accessories for Oscilloscopes - Others
Description: Rechargeable battery; 7.2V; 3500mAh
Type of test accessories: rechargeable battery
Rated voltage: 7.2V
Related items: FLK-190
Capacity: 3500mAh

Hersteller: FLUKE
Category: Calibrators - Accessories
Description: Rechargeable battery; 7.2V; 3500mAh; Ni-MH
Type of test accessories: rechargeable battery
Body dimensions: 150x56x22mm
Measuring instruments application: for Fluke 700 and 740 series calibrators
Rated voltage: 7.2V
Kind of rechargeable battery: Ni-MH
Capacity: 3500mAh

Hersteller: FLUKE
Category: Accessories - Others
Description: Torch; Resistance to: fall from 2m height
Type of test accessories: torch
Measuring instrument features: attaches to a baseball hat (includes hat clip); bright xenon lamp in a prefocused optical quality reflector; waterproof enclosure
Resistance to: fall from 2m height

Hersteller: FLUKE
Category: Inspection Cameras, Boroscopes
Description: Probe: for inspection camera; Len: 1m; Probe dia: 5.5mm; IP68
IP rating: IP68
Cable length: 1m
Related items: FLK-DS701; FLK-DS703FC
Measuring instrument features: dual view camera, from forward and side of the probe
Probe diameter: 5.5mm
Type of measuring probe: for inspection camera

Hersteller: FLUKE
Category: Meters and AC/DC Clamp Probes
Description: Meter: AC/DC current module; LCD; 3,5 digit; I DC: 400A,1kA; IP42
IP rating: IP42
Kind of display used: LCD
Display parameters: 3,5 digit
Power supply: battery LR6 AA 1,5V x2
Interface: Bluetooth
AC current measuring range: 400A; 600A
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Measurement: AC current; DC current
Measuring instrument features: 20m range
Related items: FLK-I410; FLK-I1010
Type of meter: AC/DC current module
Measurement memory: 65000
DC current measuring range: 400A; 1kA
Software: Fluke Connect
Dimensions: 160x66x38mm

Hersteller: FLUKE
Category: Meters of Env. Conditions - Others
Description: Laser level; Meas.accur: ≤3mm @ 0÷10m; Range: 30m; Laser class: 2
Body dimensions: 116x64x104mm
Operating temperature: -10...50°C
IP rating: IP54
Battery/ rechargeable battery: battery LR6 AA 1,5V x3; rechargeable battery Li-Ion PLS RBP5 3,6V 5200mAh x1
Measurement accuracy: ≤3mm @ 0...10m
Laser class: 2
Kit contents: ceiling/ wall bracket PLS UB9; charger; laser level PLS 6G; magnetic holder PLS MLB; magnetic reflective target plate for green lasers PLS GRT4; soft case PLS-60573; stand PLS FS
Tools features: automatic leveling; green laser
Power supply: battery LR6 AA 1,5V x3; rechargeable battery Li-Ion PLS RBP5 3,6V 5200mAh x1
Producer guarantee (months): 36
Vertical/horizontal viewing angle: 130/180°
Type of tool: laser level
Nominal life: 12h
Range: 30m

Hersteller: FLUKE
Category: Meters of Env. Conditions - Others
Description: Laser level; Meas.accur: ≤3mm @ 0÷10m; Range: 30m; Laser class: 2
Body dimensions: 116x64x104mm
Operating temperature: -10...50°C
IP rating: IP54
Battery/ rechargeable battery: battery LR6 AA 1,5V x3; rechargeable battery Li-Ion PLS RBP5 3,6V 5200mAh x1
Measurement accuracy: ≤3mm @ 0...10m
Laser class: 2
Kit contents: ceiling/ wall bracket PLS UB9; charger; green line laser detector with bracket PLS SLD Green; laser level PLS 6G; magnetic holder PLS MLB; magnetic reflective target plate for green lasers PLS GRT4; soft case PLS-60573; stand PLS FS
Tools features: automatic leveling; green laser
Power supply: battery LR6 AA 1,5V x3; rechargeable battery Li-Ion PLS RBP5 3,6V 5200mAh x1
Producer guarantee (months): 36
Vertical/horizontal viewing angle: 130/180°
Type of tool: laser level
Nominal life: 12h
Range: 30m

Hersteller: FLUKE
Category: Meters of Env. Conditions - Others
Description: Laser level; Meas.accur: ≤3mm @ 0÷10m; Range: 30m; Laser class: 2
Body dimensions: 116x64x104mm
Operating temperature: -10...50°C
IP rating: IP54
Battery/ rechargeable battery: battery LR6 AA 1,5V x3; rechargeable battery Li-Ion PLS RBP5 3,6V 5200mAh x1
Measurement accuracy: ≤3mm @ 0...10m
Laser class: 2
Kit contents: ceiling/ wall bracket PLS UB9; charger; laser level PLS 6R; magnetic holder PLS MLB; magnetic reflective target plate for red lasers PLS RRT4; soft case PLS-60573; stand PLS FS
Tools features: automatic leveling; red laser
Power supply: battery LR6 AA 1,5V x3; rechargeable battery Li-Ion PLS RBP5 3,6V 5200mAh x1
Producer guarantee (months): 36
Vertical/horizontal viewing angle: 130/180°
Type of tool: laser level
Nominal life: 30h
Range: 30m

Hersteller: FLUKE
Category: Meters of Env. Conditions - Others
Description: Laser level; Meas.accur: ≤3mm @ 0÷10m; Range: 30m; Laser class: 2
Body dimensions: 116x64x104mm
Operating temperature: -10...50°C
IP rating: IP54
Battery/ rechargeable battery: battery LR6 AA 1,5V x3; rechargeable battery Li-Ion PLS RBP5 3,6V 5200mAh x1
Measurement accuracy: ≤3mm @ 0...10m
Laser class: 2
Kit contents: ceiling/ wall bracket PLS UB9; charger; laser level PLS 6R; magnetic holder PLS MLB; magnetic reflective target plate for red lasers PLS RRT4; red line laser detector with bracket PLS SLD Red; soft case PLS-60573; stand PLS FS
Tools features: automatic leveling; red laser
Power supply: battery LR6 AA 1,5V x3; rechargeable battery Li-Ion PLS RBP5 3,6V 5200mAh x1
Producer guarantee (months): 36
Vertical/horizontal viewing angle: 130/180°
Type of tool: laser level
Nominal life: 30h
Range: 30m

Hersteller: FLUKE
Category: PV and EVSE Testers and Meters
Description: Meter: multifunction; VAC accuracy: ±(1%+5digit); VAC: 600V,1kV
Type of meter: multifunction
AC voltage measuring accuracy: ±(1% + 5 digit)
AC voltage measuring range: 600V; 1kV
AC current measuring accuracy: ±(2% + 5 digit)
AC current measuring range: 100mA...999.9A
DC voltage measuring accuracy: ±(1% + 5 digit)
DC voltage measuring range: 600V; 1.5kV
DC current measuring accuracy: ±(2% + 5 digit)
DC current measuring range: 100mA...999.9A
Resistance measuring accuracy: ±(1%+5 digit)
Resistance measuring range: 600Ω; 6kΩ; 60kΩ
Capacitance measuring accuracy: ±(1%+ 5 digit)
Capacitance measuring range: 0.1...100µF; 1mF
Frequency measuring accuracy: ±(0.5%+5 digit)
Frequency measuring range: 5...500Hz
True effective value measurement: True RMS
Standard equipment: case; iFlex2500-18 - current clamp; magnetic hanging strap; test leads ( 2pcs.); test leads MC4
Conform to the norm: CAT III 1500V; CAT IV 600V; EN 61010
Measuring instrument features: AUTO HOLD; automatic power-off; flexible current probe up to 2500A; HOLD function; MIN/MAX/AVG function; polarization indicator
Kind of display used: LCD
Measurement: AC current; AC voltage; capacitance; continuity; current (with current clamps); DC current; DC voltage; frequency; inrush current; peak current; resistance
Battery/ rechargeable battery: battery LR6 AA 1,5V x2
Interface: Bluetooth
Power supply: battery LR6 AA 1,5V x2
Dimensions: 281x84x49mm
Kind of meter: digital; pincers type
Illumination: yes
Software: Fluke Connect
Continuity test: acoustic indication; <30Ω
Max. diameter of measured cable: 34mm
Pollution degree: 2
CF crest factor: 1.42k @ 2.5kA; 2.5k @ 600A; 3k @ 1.1kA
Weight with battery: 520g

Hersteller: FLUKE
Category: PV and EVSE Testers and Meters
Description: Meter: multifunction; VAC accuracy: ±(1%+5digit); VAC: 600V,1kV
Type of meter: multifunction
AC voltage measuring accuracy: ±(1% + 5 digit)
AC voltage measuring range: 600V; 1kV
AC current measuring accuracy: ±(2% + 5 digit)
AC current measuring range: 100mA...999.9A
DC voltage measuring accuracy: ±(1% + 5 digit)
DC voltage measuring range: 600V; 1.5kV
DC current measuring accuracy: ±(2% + 5 digit)
DC current measuring range: 100mA...999.9A
Resistance measuring accuracy: ±(1%+5 digit)
Resistance measuring range: 600Ω; 6kΩ; 60kΩ
Capacitance measuring accuracy: ±(1%+ 5 digit)
Capacitance measuring range: 0.1...100µF; 1mF
Frequency measuring accuracy: ±(0.5%+5 digit)
Frequency measuring range: 5...500Hz
True effective value measurement: True RMS
Standard equipment: case; FLK-IRR1-SOL meter; iFlex2500-18 - current clamp; magnetic hanging strap; test leads ( 2pcs.); test leads MC4
Conform to the norm: CAT III 1500V; CAT IV 600V; EN 61010
Measuring instrument features: AUTO HOLD; automatic power-off; flexible current probe up to 2500A; HOLD function; MIN/MAX/AVG function; polarization indicator
Kind of display used: LCD
Measurement: AC current; AC voltage; capacitance; continuity; current (with current clamps); DC current; DC voltage; frequency; inrush current; peak current; resistance
Battery/ rechargeable battery: battery LR6 AA 1,5V x2
Interface: Bluetooth
Power supply: battery LR6 AA 1,5V x2
Dimensions: 281x84x49mm
Kind of meter: digital; pincers type
Illumination: yes
Software: Fluke Connect
Continuity test: acoustic indication; <30Ω
Max. diameter of measured cable: 34mm
Pollution degree: 2
CF crest factor: 1.42k @ 2.5kA; 2.5k @ 600A; 3k @ 1.1kA
Weight with battery: 520g

Hersteller: FLUKE
Category: Probes - Test Plugs
Description: Set of blades to the tip; Plating: gold-plated; Kit: 5x blade
Contact plating: gold-plated
Related items: FLK-TL910
Type of test accessories: set of blades to the tip
Alias: 1616644
Kit contents: 5x blade

Hersteller: FLUKE
Category: Indicators, Voltage & Continuity Testers
Description: Tester: proving unit; 240V; magnetic hanging strap FLK-TOOLPAK
Body dimensions: 117x74x28mm
Type of tester: proving unit
Standard equipment: magnetic hanging strap FLK-TOOLPAK
Measuring instrument features: compatible with high or low impedance multimeters; LED indicator
Power supply: battery LR6 AA 1,5V x4
Voltage source: 240V
Conform to the norm: IEC 61010-1; IEC 61010-2-030

Hersteller: FLUKE
Category: Fluke Infrared Cameras
Description: Test acces: car charger
Type of test accessories: car charger
Related items: FLK-TI10/9HZ; FLK-TI25; FLK-TI32; FLK-TIR1/9HZ; FLK-TIR32

Hersteller: FLUKE
Category: Fluke Infrared Cameras
Description: Test acces: accu pack; 2.5h; 7.4V
Type of test accessories: accu pack
Charge time: 2.5h
Body dimensions: 124x58.4x42.4mm
Rated voltage: 7.4V
Related items: FLK-TI32; FLK-TIR32

Hersteller: FLUKE
Category: Fluke Infrared Cameras
Description: Test acces: rechargeable battery; 2100mAh; 7.2V; Ni-MH
Type of test accessories: rechargeable battery
Capacity: 2.1Ah
Rated voltage: 7.2V
Related items: FLK-TI10/9HZ; FLK-TI20; FLK-TI25; FLK-TIR1/9HZ
Kind of rechargeable battery: Ni-MH

Hersteller: FLUKE
Category: Fluke Infrared Cameras
Description: Test acces: stand mount
Type of test accessories: stand mount
Related items: FLK-TI100; FLK-TI110; FLK-TI125; FLK-TIR110; FLK-TIR125

Hersteller: FLUKE
Category: Fluke Infrared Cameras
Description: Test acces: battery charger
Related items: FLK-TI200/9HZ; FLK-TI300/9HZ; FLK-TI400/9HZ; FLK-TIS10/9HZ; FLK-TIS20/9HZ; FLK-TIS40/9HZ; FLK-TIS45/9HZ; FLK-TIS50/9HZ; FLK-TIS55/9HZ; FLK-TIS60/9HZ; FLK-TIS65/9HZ; FLK-TIS75/9HZ; FLK-TIX520/9HZ; FLK-TIX560/9HZ
Type of test accessories: battery charger

Hersteller: FLUKE
Category: PV and EVSE Testers and Meters
Description: Measuring kit: photovoltaic system analyzer; photovoltaics
Type of measuring kit: photovoltaic system analyzer
Standard equipment: adapter; analyzer; backpack; carrying case; carrying strap; coupler set; FLK-I100 - current clamp; fuses; magnetic catch; mounting holder; remotely controlled probe TP1000; solar irradiance meter FLK-IRR2-BT; temperature probe FLK-80PR-IRR; test lead on reel TL1000/30M; test leads TL1000; test leads TL1000-MC4; test probe x1; USB cable
Measuring instrument features: multifunction
Related items: FLK-TRUTEST-ADV; FLK-TRUTEST-LITE
Measurement: AC current; AC voltage; DC current; DC voltage; insulation resistance; open-circuit voltage; protective conductor resistance; short-circuit current
Battery/ rechargeable battery: battery LR6 AA 1,5V x6
Power supply: battery LR6 AA 1,5V x6
Application: photovoltaics
Dimensions: 100x250x125mm
Operating temperature: 0...50°C
Storage temperature: -30...60°C

Hersteller: FLUKE
Category: PV and EVSE Testers and Meters
Description: Measuring kit: photovoltaic system analyzer; photovoltaics
Dimensions: 100x250x125mm
Operating temperature: 0...50°C
Power supply: battery LR6 AA 1,5V x6
Application: photovoltaics
Related items: FLK-TRUTEST-ADV; FLK-TRUTEST-LITE
Standard equipment: adapter; analyzer; backpack; carrying case; carrying strap; coupler set; FLK-I100 - current clamp; fuses; magnetic catch; mounting holder; PVLEAD3 Solar PV Clamp Test Lead Set; remotely controlled probe TP1000; solar irradiance meter FLK-IRR2-BT; temperature probe FLK-80PR-IRR; test lead on reel TL1000/30M; test leads TL1000; test leads TL1000-MC4; test probe x1; USB cable
Measuring instrument features: multifunction
Type of measuring kit: photovoltaic system analyzer
Storage temperature: -30...60°C
Measurement: AC current; AC voltage; DC current; DC voltage; insulation resistance; open-circuit voltage; protective conductor resistance; short-circuit current
Battery/ rechargeable battery: battery LR6 AA 1,5V x6
Software: Trutest

Hersteller: FLUKE
Category: Portable digital multimeters
Description: Digital multimeter; colour,LCD TFT 2,2"; (50000); 320x240; IP54
Type of meter: digital multimeter
Measurement: AC current; AC voltage; capacitance; DC current; DC voltage; duty cycle; frequency; resistance; temperature
Kind of display used: colour; LCD TFT 2,2"
Display parameters: (50000)
Display resolution: 320x240
Bargraph: 51 segm.
DC voltage measuring range: 0.1µV...50mV; 500mV; 5V; 50V; 500V; 1kV
DC voltage measuring accuracy: ±(0.025% + 2 digit)
AC voltage measuring range: 0.1µV...50mV; 500mV; 5V; 50V; 500V; 1kV
AC voltage measuring accuracy: ±(0.4% + 20 digit)
DC current measuring range: 10nA...500µA; 5mA; 50mA; 400mA; 5A; 10A; 20A < 30s
DC current measuring accuracy: ±(0.15% + 2 digit)
AC current measuring range: 0.01...500µA; 5mA; 50mA; 400mA; 5A; 10A; (20A <30s)
AC current measuring accuracy: ±(0.6% + 5 digit)
True effective value measurement: True RMS AC; True RMS AC+DC
Resistance measuring range: 1mΩ...50Ω; 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ; 30MΩ; 50MΩ; 100MΩ; 500MΩ
Capacitance measuring range: 1pF...1nF; 10nF; 100nF; 1µF; 10µF; 100µF; 1mF; 10mF; 100mF
Capacitance measuring accuracy: ±(1%+ 5 digit)
Frequency measuring range: 1...99999mHz; 999.99Hz; 9.9999kHz; 99.999kHz; 999.99kHz
Frequency measuring accuracy: ±(0.005%+5 digit)
Temperature measuring range: -200...1350°C
Temperature measurement accuracy: ±(1% + 1°C)
Conductance measuring accuracy: ±(1% + 10digit)
Resistance measuring accuracy: ±(0.05%+2 digit)
Temperature measurement resolution: 0.1°C
Conductance measurement: 10000000...50nS
Duty cycle factor: 1...99%
Duty cycle factor measurement accuracy: 0,2% per kHz + 0,1%
Diode test: 1mA @3.1V
Continuity test: acoustic indication
Pollution degree: 2
IP rating: IP54
Weight with battery: 871g
Power supply: battery LR6 AA 1,5V x6
Standard equipment: holder for probes; test leads FLK-TL71
Optional equipment: FLK-C781 soft cover; FLK-IR3000FC; FLK-TLK287 accessory set; FLK-TLK289 accessory set
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Related items: FLK-80BK-A; FLK-80PJ-1; FLK-80PJ-9; FLK-80PJ-EXT; FLK-80PK-1; FLK-80PK-3A; FLK-80PK-8; FLK-80PK-9; FLK-80PK-11; FLK-80PK-22; FLK-80PK-24; FLK-80PK-25; FLK-80PK-26; FLK-80PK-27; FLK-80PR-60; FLK-80PT-EXT; FLK-80T-150UA; POM-5674C; POM-6340; POM-6341
Dimensions (W x H x D): 102x222x60mm
Measuring instrument features: HOLD function; information pushbutton activating the built-in help; MIN/MAX/MEDIUM function; possibility of displaying many readouts on single screen; quick registration of MIN/MAX values (250µs); TrendCapture data registration function
Battery/ rechargeable battery: battery LR6 AA 1,5V x6
Manufacturer series: FLUKE 280
Software: Fluke Connect (FLK-IR3000FC)
Measurement memory: 10k

Hersteller: FLUKE
Category: Portable digital multimeters
Description: Digital multimeter; colour,LCD TFT 2,2"; (50000); 320x240; IP54
Type of meter: digital multimeter
Measurement: AC current; AC voltage; capacitance; DC current; DC voltage; duty cycle; frequency; resistance; temperature
Kind of display used: colour; LCD TFT 2,2"
Display parameters: (50000)
Display resolution: 320x240
Bargraph: 51 segm.
DC voltage measuring range: 0.1µV...50mV; 500mV; 5V; 50V; 500V; 1kV
DC voltage measuring accuracy: ±(0.025% + 2 digit)
AC voltage measuring range: 0.1µV...50mV; 500mV; 5V; 50V; 500V; 1kV
AC voltage measuring accuracy: ±(0.4% + 20 digit)
DC current measuring range: 10nA...500µA; 5mA; 50mA; 400mA; 5A; 10A; 20A < 30s
DC current measuring accuracy: ±(0.15% + 2 digit)
AC current measuring range: 0.01...500µA; 5mA; 50mA; 400mA; 5A; 10A; (20A <30s)
AC current measuring accuracy: ±(0.6% + 5 digit)
True effective value measurement: True RMS AC; True RMS AC+DC
Resistance measuring range: 1mΩ...50Ω; 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ; 30MΩ; 50MΩ; 100MΩ; 500MΩ
Capacitance measuring range: 1pF...1nF; 10nF; 100nF; 1µF; 10µF; 100µF; 1mF; 10mF; 100mF
Capacitance measuring accuracy: ±(1%+ 5 digit)
Frequency measuring range: 1...99999mHz; 999.99Hz; 9.9999kHz; 99.999kHz; 999.99kHz
Frequency measuring accuracy: ±(0.005%+5 digit)
Temperature measuring range: -200...1350°C
Temperature measurement accuracy: ±(1% + 1°C)
Conductance measuring accuracy: ±(1% + 10digit)
Resistance measuring accuracy: ±(0.05%+2 digit)
Temperature measurement resolution: 0.1°C
Conductance measurement: 10000000...50nS
Duty cycle factor: 1...99%
Duty cycle factor measurement accuracy: 0,2% per kHz + 0,1%
Diode test: 1mA @3.1V
Continuity test: acoustic indication
Pollution degree: 2
IP rating: IP54
Weight with battery: 871g
Power supply: battery LR6 AA 1,5V x6
Standard equipment: FLK-TL175 test leads; holder for probes
Optional equipment: FLK-C781 soft cover; FLK-IR3000FC; FLK-TLK287 accessory set; FLK-TLK289 accessory set
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Related items: FLK-80BK-A; FLK-80PJ-1; FLK-80PJ-9; FLK-80PJ-EXT; FLK-80PK-1; FLK-80PK-3A; FLK-80PK-8; FLK-80PK-9; FLK-80PK-11; FLK-80PK-22; FLK-80PK-24; FLK-80PK-25; FLK-80PK-26; FLK-80PK-27; FLK-80PR-60; FLK-80PT-EXT; FLK-80T-150UA; POM-5899A; POM-6173A; POM-7519A
Dimensions (W x H x D): 102x222x60mm
Measuring instrument features: HOLD function; information pushbutton activating the built-in help; low input impedance function (LoZ); low-pass filter for measuring drive parameters; low resistance measuring range (50Ω) for measuring motor windings resistance; MIN/MAX/MEDIUM function; possibility of displaying many readouts on single screen; quick registration of MIN/MAX values (250µs); TrendCapture data registration function
Battery/ rechargeable battery: battery LR6 AA 1,5V x6
Manufacturer series: FOX
Software: Fluke Connect (FLK-IR3000FC)
Measurement memory: 10k

Hersteller: FLUKE
Category: Accessories for Oscilloscopes - Others
Description: Rechargeable battery; 4800mAh
Type of test accessories: rechargeable battery
Measuring instruments application: for scopemeters Fluke 190 Series II
Capacity: 4800mAh
